Omron E3X-HD8 Fiber Optic Sensor

Omron E3X-HD8 is a PNP fiber amplifier designed to process optical signals from compatible fiber optic sensing heads for object detection. Its red 4-element LED operates at 625 nm, while digital tuning supports sensitivity setup according to sensing conditions. A wire-saving connector provides a compact electrical interface and supports reduced wiring in compatible multi-amplifier installations. The amplifier operates from 12 to 24 VDC and uses a polycarbonate enclosure with IP50 protection. Its PNP output provides the switching signal for compatible machine control inputs. The E3X-HD8 belongs to the E3X-HD Series within the fiber amplifier range from Omron sensing products, connecting digital fiber sensing with PNP machine control signals.

Omron E3X-HD8 Fiber Optic Sensor
BrandOmron
ProductFiber Amplifier Unit
Model NumberE3X-HD8

Omron E3X-HD8 Fiber Optic Sensor - Technical Specifications

SpecificationValue
Connection MethodWire-saving Connector
OutputPNP
Light SourceRed, 4-element LED (625 nm)
Power Supply Voltage12 to 24 VDC ±10%, ripple (P-P) 10% max.
MaterialsPolycarbonate (PC)
Degree Of Protection IpIEC 60529 IP50
Ambient Illumination Receiver SideIncandescent lamp: 20,000 lx max., Sunlight: 30,000 lx max.
Ambient Temperature RangeOperating: Groups of 1 to 2 Amplifiers: −25 to 55°C, Groups of 3 to 10 Amplifiers: −25 to 50°C, Groups of 11 to 16 Amplifiers: −25 to 45°C Storage: −30 to 70°C (with no icing or condensation)
Ambient Humidity RangeOperating and storage: 35% to 85% (with no condensation)
Insulation Resistance20 MΩ min. (at 500 VDC)
Dielectric Strength1,000 VAC at 50/60 Hz for 1 minute
Vibration Resistance Destruction10 to 55 Hz with a 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions
Shock Resistance Destruction500 m/s2 for 3 times each in X, Y, and Z directions

The Omron E3X-HD8 Fiber Amplifier processes optical detection signals from compatible fiber sensing heads and provides a PNP switching output for machine control. Its red 4-element LED operates at 625 nm, providing the optical light source for the connected fiber sensing system. Digital tuning supports sensitivity setup according to sensing conditions, while the wire-saving connector provides a compact electrical interface for compatible multi-amplifier installations. The amplifier operates from 12 to 24 VDC ±10%. Its polycarbonate enclosure carries an IP50 protection rating, while the supplied ambient-light capability reaches 20,000 lx for incandescent lighting and 30,000 lx for sunlight. The important product relationships are PNP output, digital fiber amplification, wire-saving connection, red LED sensing, sensitivity tuning and object detection. These attributes provide stronger model-selection context than weight or secondary mechanical specifications. Within the E3X-HD Series, output polarity, cable or connector method and tuning approach help distinguish related fiber amplifier models. The E3X-HD8 therefore combines PNP signal processing with connector-based installation and digital sensing adjustment. For another supplied E3X-HD PNP fiber amplifier using an M8 connector instead of the wire-saving connector, the E3X-HD44 provides a relevant related comparison.
