Omron E3NX-FA51 2M Fiber Optic Sensor

Omron E3NX-FA51 2M is a PNP fiber amplifier designed for object detection with potentiometer adjustment and twin outputs. Its red LED operates at 625 nm, while selectable Dark-ON and Light-ON modes support different output logic. A fast 0.032 ms response supports rapid optical detection. The amplifier provides 1 sensing channel, 1 external input and 2 outputs, with bank function, self-diagnosis and timer features supporting sensing control. A pre-wired 2 m cable provides the electrical connection, and the unit operates from 10 to 30 VDC. The E3NX-FA51 belongs to the E3NX-FA Series within the fiber amplifier range from Omron sensing products, combining PNP switching with external input and twin-output functionality.

Omron E3NX-FA51 2M Fiber Optic Sensor
BrandOmron
ProductFiber Amplifier Unit
Model NumberE3NX-FA51 2M

Omron E3NX-FA51 2M Fiber Optic Sensor - Technical Specifications

SpecificationValue
ShapeCuboid, rail mounting
Connection MethodPre Wired Cable, 2M Length
Sensing MethodAmplifier with potentiometer
ApplicationObject detection
FeaturesBank function, External input, Twin outputs
OutputPNP
Light SourceRed LED (625 nm)
Operation ModeDark-ON, Light-ON
Power Supply Voltage10-30 VDC
FunctionSelf-diagnosis, Timer
Response Time0.032 ms
Material HousingPolycarbonate
Number Of Channels1
Number Of Digital Inputs1
Number Of Digital Outputs2
Degree Of Protection IpIP50
WeightApprox. 115 g/ approx. 75 g

The Omron E3NX-FA51 2M Fiber Amplifier uses potentiometer adjustment for object detection and provides PNP switching through a pre-wired 2 m connection. Its red LED operates at 625 nm, while selectable Dark-ON and Light-ON modes support different sensing logic. A fast 0.032 ms response enables rapid optical signal processing. The amplifier provides 1 sensing channel, 1 external input and 2 outputs, making input and output configuration important selection characteristics. Twin outputs support multiple switching signals, while the bank function provides stored sensing settings. Self-diagnosis supports sensing-status monitoring, and the timer adds output timing control. Operation from 10 to 30 VDC supports compatible control systems, while the rail-mounting polycarbonate enclosure carries an IP50 protection rating. PNP output, potentiometer adjustment, external input, twin outputs, bank functionality and high-speed response define the model within the E3NX-FA range. These functions provide a different configuration from communication-oriented or NPN analog-output variants. For another supplied pre-wired E3NX-FA amplifier providing 2 outputs but using NPN switching with analog output capability, the E3NX-FA11AN 2M provides the closest functional comparison between the two amplifier configurations.
