Omron E3NX-FA11AN 2M Fiber Optic Sensor
Omron E3NX-FA11AN 2M is an NPN fiber amplifier designed for object detection with analog output capability. Its red LED operates at 625 nm, while selectable Dark-ON and Light-ON modes provide flexible switching logic. The amplifier uses a pre-wired 2 m cable and operates from 10 to 30 VDC with a 0.08 ms response. It provides 1 sensing channel and 2 outputs, while analog output and bank functionality extend the available signal and setting options. A timer provides additional output control. The E3NX-FA11AN 2M belongs to the E3NX-FA Series within the fiber amplifier range from Omron sensing products, combining NPN switching, analog signal output and dual-output object detection in a pre-wired amplifier configuration.

| Brand | Omron |
| Product | Fiber Amplifier Unit |
| Model Number | E3NX-FA11AN 2M |
Omron E3NX-FA11AN 2M Fiber Optic Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Shape | Cuboid, rail mounting |
| Connection Method | Pre Wired Cable, 2M Length |
| Sensing Method | Fiber amplifier |
| Application | Object detection |
| Features | Analog output, Bank function |
| Output | NPN |
| Light Source | Red LED (625 nm) |
| Operation Mode | Dark-ON, Light-ON |
| Power Supply Voltage | 10-30 VDC |
| Function | Timer |
| Response Time | 0.08 ms |
| Material Housing | Polycarbonate |
| Number Of Channels | 1 |
| Number Of Digital Outputs | 2 |
| Degree Of Protection Ip | IP50 |
| Weight | Approx. 115 g/ approx. 75 g |
The Omron E3NX-FA11AN 2M Fiber Amplifier processes optical signals for object detection and combines an NPN switching configuration with analog output capability. Its red LED operates at 625 nm, while selectable Dark-ON and Light-ON modes support different output logic requirements. The amplifier provides 1 sensing channel and 2 outputs, making output configuration an important characteristic when selecting this model. Analog output extends the available signal information beyond standard switching, while the bank function supports stored sensing settings. A timer provides additional output timing control. The pre-wired 2 m cable provides the electrical connection, and the amplifier operates from 10 to 30 VDC with a 0.08 ms response. Its rail-mounting polycarbonate enclosure carries an IP50 protection rating. NPN output, analog output, dual outputs, bank functionality, pre-wired connection and object detection are the primary attributes that define E3NX-FA11AN within the E3NX-FA range. These characteristics distinguish it from connector-based or single-output amplifier variants. For another supplied pre-wired E3NX-FA amplifier offering 2 outputs but using PNP switching, external input and a faster 0.032 ms response, the E3NX-FA51 2M provides the closest functional comparison.
