Omron E3JK-TR14-C 2M Photoelectric Sensor
The Omron E3JK-TR14-C 2M Photoelectric Sensor features a through-beam output type with a reliable 5 m detection distance. It operates on an AC/DC selectable power supply and is part of the Omron automation range under the Omron Photoelectric Sensors category and the Omron E3JK Series. This model includes an Emitter (E3JK-TR14-L 2M) and Receiver (E3JK-TR14-D 2M), powered by an Infrared LED, with a relay output and a durable 2 m pre-wired cable. It also comes with a mounting bracket for easy and stable installation.
| Brand | Omron |
| Product Type | Photoelectric Sensors |
| Model Number | E3JK-TR14-C 2M |
Omron E3JK-TR14-C 2M Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Shape | Square body |
| Sensing Method | Through-beam |
| Emitter Number | E3JK-TR14-L 2M |
| Receiver Number | E3JK-TR14-D 2M |
| Sensing Distance | 5 m |
| Light Source (wavelength) | Infrared LED (850 nm) |
| Connection Method | Pre Wired Cable, 2M Length |
| Power Supply Voltage | 24 to 240 VDC |
| Output Configuration | Relay output |
| Power Consumption | 3 W max. (Emitter 1.5 W max. Receiver 1.5 W max.) |
| Operation Mode | Light-ON/Dark-ON |
| Response time | 20 ms max |
| Degree of protection | IEC 60529 IP64 |
| Material Case | ABS (Acrylonitrile Butadiene Styrene) |
| Material Cable | PVC |
| Material Lens | Methacrylic resin |
| Features | Multi voltage power supply |
| Weight | 350 g |
The Omron E3JK-TR14-C 2M Photoelectric Sensor is a long-range through-beam type model under the Omron E3JK Series. It features a 5 m sensing distance, operates with a 24 to 240 VDC power supply, and uses a relay output configuration. The sensor provides IP64 degree of protection, making it suitable for use in dusty or humid industrial areas. This model supports both Light-ON and Dark-ON operation modes, offering flexible detection for different automation setups.
In industrial automation, the Omron E3JK-TR14-C 2M Photoelectric Sensor is commonly used for object detection on conveyor belts, packaging systems, and automated assembly lines. Its infrared LED sensing method ensures stable detection even in environments with varying light conditions. Engineers prefer this sensor for its consistent long-range performance and simple installation process, suitable for diverse control applications.
The Omron E3JK-TR14-C 2M Photoelectric Sensor is a through-beam type sensor consisting of an emitter (E3JK-TR14-L 2M) and receiver (E3JK-TR14-D 2M), providing a reliable 5 m sensing distance using an infrared LED for consistent object detection. For long-distance applications, the Omron E3JK-TR13-C 2M Photoelectric Sensor offers an extended 40 m sensing range with the same AC/DC selectable power and relay output. Alternatively, the Omron E3JK-TR14 2M Photoelectric Sensor provides identical 5 m infrared sensing performance but without the mounting bracket. For setups requiring a visible light source, the Omron E3JK-TR12-C 2M Photoelectric Sensor uses a red LED instead of infrared for enhanced alignment visibility. The E3JK-TR14-C 2M model combines AC/DC power flexibility, a pre-wired 2 m cable, and a relay output, ensuring stable performance and easy integration in industrial automation systems.
With Omronβs proven reliability and robust design, the E3JK-TR14-C 2M Photoelectric Sensor continues to serve as a dependable choice for industrial automation across manufacturing and material handling systems. Its accurate sensing capability, strong protective design, and multi-voltage power support make it a trusted model for engineers seeking precision and durability. The Omron E3JK-TR14-C 2M stands as a key product within the E3JK Series for reliable object detection in factory automation.
