Home Products Photoelectric Sensors Omron E3FA Series E3FA-RP22 Omron E3FA-RP22 Photoelectric Sensor Omron E3FA-RP22 is a PNP coaxial retro-reflective photoelectric sensor with a 0–500 mm sensing distance and an M12 connector. Its coaxial optics detect targets right up to the sensor face, and the MSR (mirror surface rejection) function prevents shiny objects from being mistaken for the E39-R1S reflector. For longer reflector spacing up to 4 m, see the E3FA-RP21. It is part of the Omron E3FA Series . Explore more Omron photoelectric sensors .
Brand Omron Product Photoelectric Sensors Model Number E3FA-RP22
Omron E3FA-RP22 Photoelectric Sensor – Technical Specifications Specification Value Sensing Method Coaxial Retro-reflective with MSR function Sensing Distance 0 to 500 mm with E39-R1S Standard Sensing Object Opaque: 75 mm dia.min. Light Source Red LED (624 nm) Power Supply Voltage 10 to 30 VDC (include voltage ripple of 10%(p-p) max.) Output Configuration PNP Connection Method M12 Connector Current Consumption 25 mA max. Control Output Load current: 100 mA max. (Residual voltage: 3 V max.), Load power supply voltage: 30 VDC max. Operation Mode Light-ON/Dark-ON selectable by wiring Response Time 0.5 ms Sensitivity Adjustment One-turn adjuster Indicators Operation indicator (orange) Stability indicator (green) Ambient Illumination Incandescent lamp: 3,000 lx max./ Sunlight: 10,000 lx max. Ambient Temperature Range Operating: -25 to 55°C/ Storage: -40 to 70°C (with no icing or condensation) Ambient Humidity Range Operating: 35 to 85%/ Storage: 35 to 95% (with no condensation) Insulation Resistance 20 MΩ min. at 500 VDC Dielectric Strength 1,000 VAC at 50/60 Hz for 1 min. between current-carrying parts and case Vibration Resistance Destruction: 10 to 55 Hz, 1.5 mm double amplitude for 2 hours each in X, Y and Z directions Shock Resistance Destruction: 500 m/s2 3 times each in X, Y and Z directions Protection Circuits Power supply reverse polarity protection, Output short-circuit protection, and Output reverse polarity protection Degree Of Protection IEC: IP67, DIN 40050-9: IP69K Material ABS, PMMA, POM, POM Weight Approx. 20 g/ Approx. 10 g
