Omron E32-T14LR 2M Fiber Optic Sensor

Omron E32-T14LR 2M is a 3 mm miniature through-beam fiber optic sensor designed for object detection at sensing distances up to 670 mm. Its cylindrical radial sensing structure creates a side-view optical direction, making the sensing-head orientation useful for compact machine layouts. Flexible miniature fiber construction supports tight routing between the sensing location and compatible fiber amplifier. The 2 m fiber uses a plastic core with a polyethylene sheath and supports a small 1 mm bending radius. IP67 protection and operation from -40 to 70°C support industrial sensing environments. The E32-T14LR 2M belongs to the E32 Series within the miniature through-beam sensor range from Omron sensing products, combining side-view detection with flexible 3 mm sensing.

Omron E32-T14LR 2M Fiber Optic Sensor
BrandOmron
ProductFiber Optic Sensor
Model NumberE32-T14LR 2M

Omron E32-T14LR 2M Fiber Optic Sensor - Technical Specifications

SpecificationValue
ShapeCylindrical radial
Sensing Distance670 mm
Sizedia 3 mm
Cable Length2 m
Sensing MethodThrough-beam
ApplicationObject detection
FeaturesFlexible fiber, Miniature
Sensing Surface OrientationSide-view
Temperature Range-40-70 °C
Bending Radius1 mm
Free Cutyes
Material CorePlastic
Material SheathPolyethylene
Degree Of Protection IpIP67

The Omron E32-T14LR 2M Fiber Optic Sensor uses through-beam sensing for object detection at distances up to 670 mm. Its cylindrical radial sensing structure has a 3 mm diameter, making miniature head size an important attribute for installations where sensing space is limited. The radial construction creates a side-view optical direction, allowing the sensing beam to leave the side of the head rather than follow an axial path. Flexible miniature fiber construction supports routing through compact machine structures. The 2 m fiber uses a plastic core with a polyethylene sheath and provides a small 1 mm bending radius. IP67 protection and operation from -40 to 70°C define the supplied environmental characteristics. The important product relationships are 3 mm miniature sensing, through-beam detection, side-view orientation, flexible fiber, radial sensing geometry and object detection. These attributes provide useful selection context without relying on weight or unrelated specifications. Within the E32 Series, head diameter, sensing orientation, fiber flexibility and detection distance help distinguish miniature through-beam sensors. The E32-T14LR therefore combines side-facing detection with flexible 3 mm construction. For another miniature E32 through-beam model using a flexible fiber and 1 mm bending radius, the E32-T223R 2M provides a relevant comparison.
