Omron E32-T15ZR 2M Fiber Optic Sensor

Omron E32-T15ZR 2M is a flat-view through-beam fiber optic sensor designed for object detection at sensing distances up to 1120 mm. Its square sensing head provides a different mounting geometry from threaded and cylindrical E32 models, while the flat-view sensing surface defines the optical direction toward the target. Flexible fiber construction supports cable routing through compact spaces, and the pre-wired 2 m cable uses a plastic core with a PVC sheath. The R1 fiber configuration further supports tight routing. IP67 protection and operation from -40 to 70°C support industrial sensing conditions. The E32-T15ZR 2M belongs to the E32 Series within the through-beam fiber sensor range from Omron sensing products, combining square construction with flexible flat-view detection.

Omron E32-T15ZR 2M Fiber Optic Sensor
BrandOmron
ProductFiber Optic Sensor
Model NumberE32-T15ZR 2M

Omron E32-T15ZR 2M Fiber Optic Sensor - Technical Specifications

SpecificationValue
ShapeSquare
Sensing Distance1120 mm
Connection MethodPre-wired Cable
Cable Length2 m
Sensing MethodThrough-beam
ApplicationObject detection
FeaturesFlexible fiber
Sensing Surface OrientationFlat-view
Tightening Torque0.15N · m
Temperature Range-40-70 °C
Bending RadiusR1
Material CorePlastic
Material SheathPVC
Degree Of Protection IpIP67

The Omron E32-T15ZR 2M Fiber Optic Sensor uses through-beam sensing for object detection at distances up to 1120 mm. Its square sensing head and flat-view optical surface create a sensing geometry that differs from cylindrical axial, radial and threaded E32 models. This flat-view arrangement makes sensing direction an important factor when positioning the fiber head relative to the target. Flexible fiber construction supports routing through restricted spaces, while the pre-wired 2 m cable uses a plastic core with a PVC sheath. The R1 fiber configuration further supports tight cable routing. IP67 protection and operation from -40 to 70°C define the supplied environmental characteristics. Through-beam detection, square head construction, flat-view sensing, flexible fiber and 1120 mm sensing distance are the primary characteristics for selecting this model. These attributes provide a clear distinction from models using side-view or top-view sensing surfaces. E32-T15ZR therefore combines a square optical head with flexible medium-range through-beam detection. For another supplied square E32 through-beam model using flexible fiber but a top-view sensing orientation and longer 4000 mm sensing distance, the E32-T16JR 2M provides a relevant comparison of sensing orientation and detection range.
