Omron E32-T14 2M Fiber Optic Sensor
Omron E32-T14 2M is a side-view through-beam fiber optic sensor designed for long-distance detection at sensing ranges up to 4000 mm. Its square sensing structure creates a compact optical head, while the side-view orientation directs the sensing path from the side of the sensor. R25 fiber construction provides a 25 mm bending radius for cable routing, and the 2 m fiber uses a plastic core with a polyethylene sheath. The long sensing distance and side-facing optical arrangement are the main characteristics that distinguish this model within the E32 range. IP67 protection supports industrial sensing conditions. The E32-T14 2M belongs to the E32 Series within the through-beam fiber sensor range from Omron sensing products, combining square construction with extended side-view detection.

| Brand | Omron |
| Product | Fiber Optic Sensor |
| Model Number | E32-T14 2M |
Omron E32-T14 2M Fiber Optic Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Shape | Square |
| Sensing Distance | 4000 mm |
| Connection Method | Cable |
| Cable Length | 2 m |
| Sensing Method | Through-beam |
| Application | Long distance detection |
| Sensing Surface Orientation | Side-view |
| Tightening Torque | 0.49N · m |
| Temperature Range | -40-70 °C |
| Bending Radius | R25 |
| Material Core | Plastic |
| Material Sheath | Polyethylene |
| Degree Of Protection Ip | IP67 |
The Omron E32-T14 2M Fiber Optic Sensor uses through-beam sensing for long-distance detection at ranges up to 4000 mm. Its square sensing structure creates a different mounting geometry from threaded and cylindrical E32 fiber heads, while the side-view orientation directs the optical path from the side of the sensing head. This sensing direction is one of the model's defining characteristics when comparing related through-beam sensors. The 2 m fiber uses a plastic core with a polyethylene sheath and provides an R25 bending radius for cable routing. IP67 protection and operation from -40 to 70°C define the supplied environmental characteristics. Through-beam sensing, 4000 mm detection distance, square construction, side-view orientation and polyethylene fiber sheath are the main attributes defining E32-T14. These characteristics distinguish the model from top-view and flat-view E32 configurations while retaining extended detection capability. The sensor therefore combines long-range optical detection with a side-facing square sensing head. For another supplied square E32 through-beam model with the same 4000 mm sensing distance but using top-view sensing and flexible fiber construction, the E32-T16JR 2M provides a useful related comparison of optical orientation and fiber configuration.
