Omron E32-A03-1 2M Fiber Optic Sensor

Omron E32-A03-1 2M is a 3.5 mm through-beam fiber optic sensor designed for object detection and wafer mapping at sensing distances up to 4000 mm. Its cylindrical radial sensing head uses a side-view orientation, allowing the optical path to exit from the side rather than along the sensor axis. The 2 m fiber uses a plastic core with a polyethylene sheath and has an R10 bending radius for cable routing. This combination of miniature sensing geometry and extended detection range supports applications where sensing-head size and optical direction are important. The E32-A03-1 2M belongs to the E32 Series within the through-beam fiber sensor range from Omron sensing products, connecting side-view sensing with long-distance object detection.

Omron E32-A03-1 2M Fiber Optic Sensor
BrandOmron
ProductFiber Optic Sensor
Model NumberE32-A03-1 2M

Omron E32-A03-1 2M Fiber Optic Sensor - Technical Specifications

SpecificationValue
ShapeCylindrical radial
Sensing Distance4000 mm
Connection MethodCable
Sizedia 3.5 mm
Cable Length2 m
Sensing MethodThrough-beam
ApplicationObject detection, Wafer mapping
Sensing Surface OrientationSide-view
Tightening Torque0.29N · m
Temperature Range40-70 °C
Bending RadiusR10
Material CorePlastic
Material SheathPolyethylene
Degree Of Protection IpIP50

The Omron E32-A03-1 2M Fiber Optic Sensor uses through-beam sensing for object detection and wafer mapping at distances up to 4000 mm. Its cylindrical radial sensing head has a 3.5 mm diameter, providing a compact sensing point where head dimensions and optical direction are important. The radial structure creates a side-view sensing path rather than directing the beam along the sensor axis. This arrangement helps define how the sensing head can be positioned relative to the target. The 2 m fiber uses a plastic core with a polyethylene sheath and has an R10 bending radius for cable routing between the sensing point and compatible fiber amplifier. IP50 protection defines the supplied enclosure rating. Important characteristics include through-beam detection, wafer mapping, side-view sensing, miniature radial construction and extended 4000 mm sensing distance. Within the E32 Series, head diameter, optical orientation, sensing principle, target application and cable construction help distinguish specialized fiber heads. The E32-A03-1 therefore combines a compact side-facing sensing head with long-distance through-beam detection. For another supplied A-series model designed for through-beam object detection and wafer mapping with a smaller cylindrical radial sensing head, the E32-A04 2M provides a closely related comparison.
