Omron E32-A12 2M Fiber Optic Sensor
Omron E32-A12 2M is a limited-reflective fiber optic sensor designed for transparent object detection at a sensing distance of 30 mm. Its square sensing structure provides a compact optical head, while the flat-view orientation directs the sensing surface toward the target. R25 fiber construction provides a 25 mm bending radius for cable routing. The pre-wired 2 m fiber uses a plastic core with a polyethylene sheath and supports free cutting for installation adjustment. Operation from -40 to 70°C and IP40 protection define its environmental characteristics. The E32-A12 2M belongs to the E32 Series within the limited-reflective fiber sensor range from Omron sensing products.

| Brand | Omron |
| Product | Fiber Optic Sensor |
| Model Number | E32-A12 2M |
Omron E32-A12 2M Fiber Optic Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Shape | Square |
| Sensing Distance | 30 mm |
| Connection Method | Pre Wired Cable, 2M Length |
| Sensing Method | Limited reflective |
| Application | Transparent object detection |
| Features | R25 fiber |
| Temperature Range | -40-70 °C |
| Bending Radius | 25 mm |
| Free Cut | yes |
| Material Core | Plastic |
| Sensing Direction | Flat-view |
| Material Sheath | Polyethylene |
| Degree Of Protection Ip | IP40 |
The Omron E32-A12 2M Fiber Optic Sensor uses limited-reflective sensing for transparent object detection at a specified sensing distance of 30 mm. Its square sensing structure provides a compact optical head, while the flat-view orientation defines how the sensing surface faces the target. This combination of limited-reflective operation and transparent object detection distinguishes E32-A12 2M from E32 models intended for general object sensing. R25 fiber construction provides a 25 mm bending radius, while the pre-wired 2 m fiber uses a plastic core with a polyethylene sheath. Free-cut capability allows the fiber length to be adjusted during installation. Operation from -40 to 70°C and IP40 protection define the supplied environmental characteristics. Limited-reflective sensing, a 30 mm sensing distance, transparent object detection, square construction and flat-view orientation are therefore the main attributes defining this model. These characteristics are useful when comparing E32 fiber units because sensing method, detection distance, head structure and sensing direction can differ significantly between models. E32-A12 combines short-range transparent object sensing with a compact square fiber head. For another E32 model using diffuse-reflective sensing with a compact cylindrical structure, the E32-C42S 1M provides a related option for comparing sensing principle, distance and optical-head configuration.
