Omron E2FM-X5B1-M1 Proximity Sensor
The Omron E2FM-X5B1-M1 Proximity Sensor offers Inductive, M18, Shielded, 5 mm Sensing distance, DC 3-Wire PNP NO, M12 Connector, 12 to 24 VDC Power supply voltage. Manufactured by Omron under the Omron Proximity Sensors category, this model belongs to the Omron E2FM Series.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2FM-X5B1-M1 |
Omron E2FM-X5B1-M1 Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Inductive |
| Size | M18 |
| Mounting type | Shielded |
| Sensing Distance | 5 mm |
| Setting Distance | 0 to 3.5 mm |
| Output configuration | DC 3-Wire PNP |
| Operation Mode | NO |
| Connection Method | M12 Connector |
| Detectable Object | Ferrous metal |
| Standard Sensing Object | Iron, 30 Γ 30 Γ 1 mm |
| Response Frequency | 100 Hz |
| Power Supply Voltage | 12 to 24 VDC |
| Protection Circuit | Reversed power supply polarity protection, Surge suppressor, Load short-circuit protection, and Reversed output polarity protection (except the E2FM-X1R5B1-M1) |
| Ambient Temperature Range | Operating/Storage: β25 to 70Β°C (with no icing or condensation) |
| Degree of Protection | IEC 60529 IP67 |
| Control Output | 200 mA max. |
| Indicators | Operation indicator (yellow LED) |
| Materials | Stainless steel (SUS303), Zinc-plated iron |
| Weight | Approx. 75 g |
The Omron E2FM-X5B1-M1 is often compared with other models in the E2FM Proximity Sensor group due to shared installation characteristics and consistent sensing behavior. Engineers frequently evaluate Omron E2FM-X1R5D1 2M (M8, 1.5 mm sensing, 3 to 100 mA, 2 M Cable), Omron E2FM-X2B1-M1 (M12, 2 mm sensing), and Omron E2FM-X10B1-M1 (M30, 10 mm sensing) when selecting suitable alternatives. This ensures compatibility when matching size, sensing distance, wiring style, output logic, or connector format. The E2FM-X5B1-M1 integrates smoothly into machinery, fixtures, conveyors, and automation systems requiring dependable detection from an Omron Proximity Sensor with All-Stainless Housing.
