Omron E2EQ-X10D1-M1GJ 0.5M Proximity Sensor
The Omron E2EQ-X10D1-M1GJ 0.5M Proximity Sensor offers Inductive, M30, Shielded, 10 mm Sensing distance, DC 2-wire NO, M12 Pre-wired Standard Connector 0.5 M Cable, 12 to 24 VDC Power supply voltage. Manufactured by Omron under the Omron Proximity Sensors category, this model belongs to the Omron E2EQ Series.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2EQ-X10D1-M1GJ 0.5M |
Omron E2EQ-X10D1-M1GJ 0.5M Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Inductive |
| Size | M30 |
| Mounting type | Shielded |
| Sensing Distance | 10 mm |
| Setting Distance | 0 to 8 mm |
| Output configuration | DC 2-wire |
| Operation Mode | NO |
| Connection Method | M12 Pre-wired Standard Connector 0.5 M Cable |
| Detectable Object | Ferrous metal |
| Standard Sensing Object | Iron, 30 × 30 × 1 mm |
| Response Frequency | 400 Hz |
| Power Supply Voltage | 12 to 24 VDC |
| Protection Circuit | Load short-circuit protection, Surge suppressor |
| Ambient Temperature Range | Operating/Storage: −25 to 70°C (with no icing or condensation) |
| Degree of Protection | IEC 60529 IP67, in-house standards: oil-resistant |
| Control Output | 3 to 100 mA |
| Indicators | Operation indicator (red), Setting indicator (green) |
| Materials | Fluororesin coating (Base material: brass) , Fluororesin, Fluororesin coating (Base material: brass) , Zinc-plated iron. |
| Weight | Approx. 190 g |
The Omron E2EQ-X10D1-M1GJ 0.5M is often compared with other models in the E2EQ group due to shared installation characteristics and consistent sensing behavior. Engineers frequently evaluate Omron E2EQ-X10C130-M1TJ 0.3M (DC 3-wire PNP, M12 Smartclick Connector 0.3 M Cable), Omron E2EQ-X10D1-M1GJ 0.3M (M12 Standard Connector 0.3 M Cable), and Omron E2EQ-X12B1D18 2M (M18, 12 mm sensing, DC 3-wire PNP, 2 M Cable) when selecting suitable alternatives. This ensures compatibility when matching size, sensing distance, wiring style, output logic, or connector format. The E2EQ-X10D1-M1GJ 0.5M integrates smoothly into machinery, fixtures, conveyors, and automation systems requiring dependable detection from an Omron Proximity Sensor.
