Omron E2EF-QX12D1-M1TGJ 0.3M Proximity Sensor
Omron E2EF-QX12D1-M1TGJ 0.3M uses an M30 shielded body with 12 mm sensing and DC 2-wire normally open operation. An M12 pre-wired Smartclick connector with a 0.3 m cable provides connection, while the setting range extends from 0 to 8.4 mm. Operating voltage covers 10 to 30 VDC with a 50 Hz response frequency. The E2EF-QX12D1-M1TGJ 0.3M belongs to the E2EF Series, while related stainless sensing options can be explored through the M30 2-wire proximity sensor range offered from Omron Industrial Products.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2EF-QX12D1-M1TGJ 0.3M |
Omron E2EF-QX12D1-M1TGJ 0.3M Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Inductive |
| Size | M30 |
| Mounting type | Shielded |
| Sensing Distance | 12mm |
| Setting Distance | 0 to 8.4mm |
| Output configuration | DC 2-Wire |
| Operation Mode | NO |
| Connection Method | M12 Pre-wired Smartclick Connector 0.3 M Cable |
| Detectable Object | Ferrous metal |
| Standard Sensing Object | Iron, 54 × 54 × 1 mm |
| Response Frequency | 50Hz |
| Power Supply Voltage | 10 to 30 VDC |
| Protection Circuit | Surge suppressor, Load short-circuit protection |
| Ambient Temperature Range | Operating : −10 to 70°C, Storage : −25 to 70°C (with no icing or condensation) |
| Degree of Protection | IEC 60529 IP67 |
| Control Output | 3 to 100 mA |
| Indicators | Operation indicator (red LED), Setting indicator (green LED) |
| Materials | Stainless steel (SUS303), Zinc-plated iron, PVC (flame retardant). |
| Weight | Approx. 190 g |
The Omron E2EF-QX12D1-M1TGJ 0.3M Proximity Sensor uses an M30 shielded body with a 12 mm sensing distance and a setting range from 0 to 8.4 mm. DC 2-wire normally open operation is provided through an M12 pre-wired Smartclick connector with a 0.3 m cable. The operating supply is 10 to 30 VDC with a 50 Hz response frequency, while ferrous metal is specified using an iron 54 × 54 × 1 mm standard object. Load current ranges from 3 to 100 mA. Surge suppression and load short-circuit protection are included. The sensor includes red operation and green setting indicators. Stainless steel, zinc-plated iron, and flame-retardant PVC are listed among the material details for the E2EF construction.
For an Omron M30 proximity sensor requiring shielded 12 mm sensing, two-wire NO operation, and Smartclick connection, the specified version is the E2EF-QX12D1-M1TGJ. Operating temperature covers -10 to 70°C and storage extends from -25 to 70°C, with IEC 60529 IP67 listed. Its configuration also suits Omron 2-wire proximity sensor, Omron 12 mm proximity sensor, Omron shielded proximity sensor, and Omron Smartclick proximity sensor requirements. The M30 body provides the largest threaded format among the models in this batch, together with the longest sensing distance. For a related E2EF M30 shielded 12 mm two-wire NO model with a pre-wired 2 m cable, see E2EF-X12D1 2M.
