Omron E2E-X7D2-M1GJ 0.3M Proximity Sensor
Omron E2E-X7D2-M1GJ 0.3M is a cylindrical M18 shielded inductive proximity sensor with a 7 mm sensing distance and a 0 to 5.6 mm setting distance. It provides DC 2-wire NC switching through an M12 standard prewired connector with a 0.3 m cable and operates from 12 to 24 VDC. Ferrous metal is the specified detectable object, with an iron 18 × 18 × 1 mm standard sensing object. Response frequency is 0.5 kHz, while control output is rated from 3 to 100 mA with a 50 mA diagnostic output. The E2E-X7D2-M1GJ 0.3M is included among M18 shielded DC proximity sensors from Omron industrial sensing products.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2E-X7D2-M1GJ 0.3M |
Omron E2E-X7D2-M1GJ 0.3M Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Inductive |
| Housing Shape | Cylindrical |
| Size | M18 |
| Mounting type | Shielded |
| Sensing Distance | 7 mm |
| Setting Distance | 0 to 5.6 mm |
| Output configuration | DC 2-wire |
| Operation Mode | NC |
| Connection Method | M12 Standard Prewired Connector 0.3 M Cable |
| Cable specifications | PVC (oil-resistant) |
| Wire color / pin arrangement | 1: +V, 2: 0 V |
| Detectable Object | Ferrous metal |
| Standard Sensing Object | Iron, 18 × 18 × 1 mm |
| Response Frequency | 0.5 kHz |
| Power Supply Voltage | 12 to 24 VDC |
| Protection Circuit | Surge suppressor, Load short-circuit protection (for control and diagnostic output) |
| Ambient Temperature Range | Operating: −25 to 70°C, Storage: −40 to 85°C (with no icing or condensation) |
| Degree of Protection | IEC 60529 IP67 |
| Control Output | 3 to 100 mA, Diagnostic output: 50 mA |
| Indicators | Operation indicator (red) |
| Materials | Nickel-plated brass, Polybutylene terephthalat (PBT), Nickel-plated brass, Zinc-plated iron, Vinyl chloride (PVC). |
| Weight | Approx. 70 g |
The Omron E2E-X7D2-M1GJ 0.3M Proximity Sensor uses a cylindrical M18 shielded inductive sensing body with a 7 mm sensing distance and a 0 to 5.6 mm setting distance. It provides DC 2-wire NC operation through an M12 standard prewired connector with a 0.3 m PVC cable and operates from 12 to 24 VDC. Ferrous metal is the specified detectable object, with an iron 18 × 18 × 1 mm standard sensing object. Response frequency is 0.5 kHz. Control output is rated from 3 to 100 mA, while diagnostic output is rated 50 mA. A red operation indicator is provided, with surge suppression and load short-circuit protection specified.
Operating conditions for the E2E-X7D2-M1GJ cover -25 to 70°C, while storage extends from -40 to 85°C without icing or condensation. IEC 60529 IP67 is specified for environmental protection. Nickel-plated brass, PBT, zinc-plated iron, and PVC are listed among the construction materials. The shielded M18 configuration supports mounting close to surrounding metal and pairs a 7 mm sensing range with DC 2-wire NC switching. The 0.3 m prewired connector supports a short detachable connection arrangement, while ferrous metal remains the stated target. For another E2E sensor using an M18 body and DC 2-wire operation with a longer 14 mm sensing distance, see E2E-X14MD1-M1.
