Omron E2E-X5Y2-M1 Proximity Sensor
Omron E2E-X5Y2-M1 is an M18 shielded inductive proximity sensor with a 5 mm sensing distance and a 0 to 4 mm setting distance. It provides an AC 2-wire NC output through an M12 connector and operates from 24 to 240 VAC. Ferrous metal is the specified detectable object, with an iron 18 × 18 × 1 mm standard sensing object. Response frequency is 25 Hz, control-output current is 5 to 100 mA, voltage drop is 3 V max., and differential travel is 10% max. of sensing distance. A red operation indicator, surge suppression, and IP67 protection are specified. The E2E-X5Y2-M1 is listed among AC proximity sensors from Omron sensing products.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2E-X5Y2-M1 |
Omron E2E-X5Y2-M1 Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Inductive |
| Size | M18 |
| Mounting | Shielded |
| Sensing Distance | 5 mm |
| Setting Distance | 0 to 4 mm |
| Output Configuration | AC 2-Wire |
| Operation Mode | NC |
| Connection | M12 Connector |
| Differential Travel | 10% max. of sensing distance |
| Detectable Object | Ferrous metal (The sensing distance decreases with non-ferrous metal. Refer to Engineering Data on page 11.) |
| Standard Sensing Object | Iron, 18 × 18 × 1 mm |
| Response Frequency | 25 Hz |
| Control Output Residual Voltage | 3 V max. |
| Control Output Load Current | 5 to 100 mA |
| Indicator | Operation indicator (red) |
| Protection Circuit | Surge suppressor |
| Ambient Temperature Range | Operating/Storage: −25 to 70°C (with no icing or condensation) |
| Ambient Humidity Range | Operating/storage: 35% to 95% (with no condensation) |
| Pin Arrangement | (1, 2): (AC, AC) |
| Insulation Resistance | ±10% max. of sensing distance at 23°C in the temperature range of −25 to 70°C |
| Dielectric Strength | 50 MΩ min. (at 500 VDC) between current-carrying parts and case |
| Vibration Resistance | Destruction: 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions |
| Voltage Influence | ±1% max. of sensing distance at rated voltage in the rated voltage ±15% range |
| Material Case | Nickel-plated brass |
| Material Toothed Washer | Zinc-plated iron |
| Material Sensing Surface | PBT |
| Material Clamping Nut | Nickel-plated brass |
| Degree Of Protection | Pre-wired Models: IEC 60529 IP67, in-house standards: oil-resistant Connector Models: IEC 60529 IP67 |
| Weight | Approx. 40 g |
The Omron E2E-X5Y2-M1 Proximity Sensor uses an M18 shielded inductive sensing body with a 5 mm sensing distance and a 0 to 4 mm setting distance. It provides an AC 2-wire NC output through an M12 connector and operates from 24 to 240 VAC. Ferrous metal is the specified detectable object, with an iron 18 × 18 × 1 mm standard sensing object. Response frequency is 25 Hz, control-output current is 5 to 100 mA, voltage drop is 3 V max., and differential travel is 10% max. of sensing distance. A red operation indicator is provided, while a surge suppressor is specified for electrical protection.
Operating and storage conditions for the E2E-X5Y2-M1 are -25 to 70°C without icing or condensation, with humidity from 35% to 95%. Temperature influence is ±10% max. of sensing distance at 23°C across the stated range. Insulation resistance is 50 MΩ min. at 500 VDC, dielectric strength is 4,000 VAC for 1 minute, and voltage influence is ±1% max. within rated voltage ±15%. Nickel-plated brass is specified for the case and fastening component, zinc-plated iron for another metal part, and PBT for the sensing surface. Connector models carry IEC 60529 IP67 protection. For another shielded AC 2-wire NC E2E model with a smaller M12 body and a 2 mm sensing distance, see E2E-X2Y2-M1.
