Omron E2E-X50MC2L30-M1 Proximity Sensor
The Omron E2E-X50MC2L30-M1 Proximity Sensor offers Inductive, M30, Unshielded, 50 mm Sensing distance, DC 3-Wire NPN NC, Long Body, M12 Connector, 10 to 30 VDC Power supply voltage. Manufactured by Omron under the Omron Proximity Sensors category, this model belongs to the Omron E2E Series.
| Brand | Omron |
| Product Type | Proximity Sensor |
| Model Number | E2E-X50MC2L30-M1 |
Omron E2E-X50MC2L30-M1 Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Size | M30 |
| Mounting type | Unshielded |
| Sensing Distance | 50 mm |
| Setting Distance | 0 to 38.2 mm |
| Output configuration | DC 3-Wire NPN |
| Operation Mode | NC |
| Body Length | Long Body |
| Connection Method | M12 Connector |
| Detectable Object | Ferrous metals |
| Standard Sensing Object | Iron, 150 Γ 150 Γ 1 mm |
| Response Frequency | 100 Hz |
| Power Supply Voltage | 10 to 30 VDC |
| Protection Circuit | Power supply reverse polarity protection, Surge suppressor, Output short-circuit protection, Output reverse polarity protection |
| Ambient Temperature Range | Operating/Storage: -25 to 70Β°C |
| Degree of Protection | IEC 60529: IP67, ISO 20653 |
| Control Output | 1-output models: 10 to 30 VDC, Class 2, 50 mA max. |
| Indicators | In the Standard I/O mode (SIO mode): Operation indicator (orange, lit) and communication indicator (green, not lit) In the IO-Link communication mode (COM mode): Operation indicator (orange, lit) and communication indicator (green, blinking at 1 s intervals) |
| Materials | Nickel-plated brass, Polybutylene terephthalat (PBT), Nickel-plated brass, Zinc-plated iron, Vinyl chloride (PVC). |
| Weight | Approx. 230 g |
The Omron E2E-X50MC2L30-M1 is often compared with other models in the E2E Proximity Sensor group due to shared installation characteristics and consistent sensing behavior. Engineers frequently evaluate Omron E2E-X6C1L12 2M (M12, 6 mm sensing, NO, Pre-wired 2 M Cable), Omron E2E-X2MB1DL8-M1TJ 0.3M (M8, 2 mm sensing, DC 3-Wire PNP, NO, M12 Pre-wired Smartclick Connector 0.3 M Cable), and Omron E2E-X16MB218-M1 (M18, 16 mm sensing, DC 3-Wire PNP) when selecting suitable alternatives. This ensures compatibility when matching size, sensing distance, wiring style, output logic, or connector format. The E2E-X50MC2L30-M1 integrates smoothly into machinery, fixtures, conveyors, and automation systems requiring dependable detection from an Omron Proximity Sensor.
