E2E-X2D1-N 2M - Omron Stainless Steel Proximity Sensor
The Omron E2E-X2D1-N 2M is a compact stainless steel M8 proximity sensor offering a precise 2 mm sensing distance and DC 2-wire NO output. Designed for industrial applications in tight spaces, it features a shielded body and 2-meter oil-resistant pre-wired cable for reliable detection in demanding environments.
| Spec | Value |
|---|---|
| Brand | Omron |
| Product Type | Proximity Sensors |
| Product | E2E-X2D1-N 2M |
Omron Stainless Steel Proximity Sensor E2E-X2D1-N 2M Technical Specifications:
| Specification | Value |
|---|---|
| Size | M8 |
| Mounting type | Shielded |
| Sensing Distance | 2 mm |
| Setting distance | 0 to 1.6 mm |
| Output type | DC 2-Wire |
| Operation mode | NO |
| Power supply | 12 to 24 VDC, ripple (p-p): 10% max. (10 to 30 VDC) |
| Connection method | Pre-wired Models(2 m) |
| Cable Specifications | PVC (oil-resistant) |
| Differential travel | 15% max. of sensing distance |
| Detectable object | Ferrous metal (The sensing distance decreases with non-ferrous metal.) |
| Standard target | Iron, 8 × 8 × 1 mm |
| Response frequency | 1.5 kHz |
| Leakage current | 0.8 mA max. |
| Indicator | Operation indicator (red) and setting indicator (green) |
| Protection circuit | Load short-circuit protection, Surge suppressor, Reverse polarity protection |
| Ambient temperature range | Operating/Storage: −40 to 85°C (with no icing or condensation) |
| Ambient humidity | Operating/Storage: 35% to 95% (with no condensation) |
| Temperature influence | ±15% max. of sensing distance at 23°C in the temperature range of −40 to 85°C ±10% max. of sensing distance at 23°C in the temperature range of −25 to 70°C |
| Voltage influence | ±1% max. of sensing distance at rated voltage in the rated voltage ±15% range |
| Insulation resistance | 50 MΩ min. (at 500 VDC) between current-carrying parts and case |
| Dielectric strength | 1000 VAC, 50/60 Hz for 1 minute between current carry parts and case |
| Vibration resistance | Destruction: 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions |
| Shock resistance | Destruction: 500 m/s2 10 times each in X, Y, and Z directions |
| Degree of protection | IP67 |
| Weight | Approx. 60 g |
🛠️ Get Quotes Instantly from Omron Vendors
Logic Shift- Powered by WAWM
✔ Verified🌟 Trusted Vendor
M.K Electricals
✔ Verified🌟 Trusted Vendor
Firefly Automation
✔ Verified🌟 Trusted Vendor
Optimized for close-range metal sensing, the Omron E2E-X2D1-N 2M features a rugged M8 shielded cylindrical design with a 2 mm sensing range, ideal for detecting small ferrous objects such as 8 × 8 × 1 mm iron targets. The DC 2-wire NO configuration ensures simple wiring and compatibility with a wide range of control systems.
Operating on a 12 to 24 VDC supply (10–30 VDC range), the sensor delivers high-speed response with a 1.5 kHz switching frequency and ultra-low current consumption at 0.8 mA max.. It includes advanced protections like load short-circuit protection, surge suppression, and reverse polarity protection. Visual feedback is provided via dual LEDs: a red operation indicator and a green setting indicator.
With a durable IP67-rated stainless steel housing and oil-resistant PVC cable, the E2E-X2D1-N 2M performs reliably across extreme temperatures from −40°C to 85°C. It’s vibration and shock resistant, making it ideal for robotics, compact machines, and harsh industrial settings. Part of the trusted Omron E2E Series, it offers precision, reliability, and durability in every sensing application.
