Omron E2E-X10D2-M1TGJ-U 0.3M Proximity Sensor
Omron E2E-X10D2-M1TGJ-U 0.3M is an M30 shielded inductive proximity sensor with a 10 mm sensing distance and a 0 to 8 mm setting distance. It uses a DC 2-wire NC output through an M12 pre-wired Smartclick connector with a 0.3 m PUR cable and operates from 12 to 24 VDC. Ferrous metal is the specified detectable object, with an iron 30 × 30 × 1 mm standard sensing object. Response frequency is 0.4 kHz, control-output current is 3 to 100 mA, and voltage drop is 3 V max. The E2E-X10D2-M1TGJ-U 0.3M is listed among DC 2-wire proximity sensors from Omron industrial sensors.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2E-X10D2-M1TGJ-U 0.3M |
Omron E2E-X10D2-M1TGJ-U 0.3M Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Inductive |
| Size | M30 |
| Mounting | Shielded |
| Sensing Distance | 10 mm |
| Setting Distance | 0 to 8 mm |
| Output Configuration | DC 2-Wire |
| Operation Mode | NC |
| Connection | M12 Pre-wired Smartclick Connector, 0.3 m Length |
| Cable Specifications | PUR |
| Differential Travel | 10% max. of sensing distance |
| Detectable Object | Ferrous metal (The sensing distance decreases with non-ferrous metal. Refer to Engineering Data on pages 10 and 11. |
| Standard Sensing Object | Iron, 30 × 30 × 1 mm |
| Response Frequency | 0.4 kHz |
| Control Output Residual Voltage | 3 V max. (Load current: 100 mA, Cable length: 2 m) |
| Control Output Load Current | 3 to 100 mA, Diagnostic output: 50 mA for -D1(5)S Models |
| Indicator | Green Indicator |
| Protection Circuit | Surge suppressor, Load short-circuit protection (for control and diagnostic output) |
| Ambient Temperature Range | Operating: −25 to 70°C, Storage: −40 to 85°C (with no icing or condensation) |
| Ambient Humidity Range | Operating/storage: 35% to 95% (with no condensation) |
| Pin Arrangement | 1: +V, 4: 0 V E |
| Insulation Resistance | ±15% max. of sensing distance at 23°C in the temperature range of −25 to 70°C |
| Dielectric Strength | 50 MΩ min. (at 500 VDC) between current-carrying parts and case |
| Vibration Resistance | Destruction: 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions |
| Voltage Influence | ±1% max. of sensing distance at rated voltage in the rated voltage ±15% range |
| Material Case | Stainless steel (SUS303) |
| Material Toothed Washer | Zinc-plated iron |
| Material Sensing Surface | PBT |
| Material Clamping Nut | Nickel-plated brass |
| Degree Of Protection | Pre-wired Models: IEC 60529 IP67, in-house standards: oil-resistant |
The Omron E2E-X10D2-M1TGJ-U 0.3M Proximity Sensor uses an M30 shielded inductive sensing body with a 10 mm sensing distance and a 0 to 8 mm setting distance. It provides a DC 2-wire NC output through an M12 pre-wired Smartclick connector with a 0.3 m PUR cable and operates from 12 to 24 VDC. Ferrous metal is the specified detectable object, with an iron 30 × 30 × 1 mm standard sensing object. Response frequency is 0.4 kHz, control-output current is 3 to 100 mA, and voltage drop is 3 V max. A green indicator is provided, while surge suppression and load short-circuit protection for the control and diagnostic output are specified.
Operating temperature for the E2E-X10D2-M1TGJ-U is -25 to 70°C, while storage extends from -40 to 85°C with humidity from 35% to 95%. Temperature influence is ±15% max. of sensing distance at 23°C across -25 to 70°C. Insulation resistance is 50 MΩ min. at 500 VDC, dielectric strength is 1,000 VAC for 1 minute, and voltage influence is ±1% max. within rated voltage ±15%. SUS303 stainless steel, zinc-plated iron, PBT, and nickel-plated brass are listed among the materials, with IP67 and oil-resistant protection for the pre-wired format. For another shielded DC 2-wire NC E2E sensor with an M18 body and 7 mm sensing distance, see E2E-X7D2-M1.
