Omron E2E-X10D1-N 2M Proximity Sensor
Omron E2E-X10D1-N 2M is an M30 shielded inductive proximity sensor with a 10 mm sensing distance and a 0 to 8 mm setting distance. It uses a DC 2-wire NO output, a pre-wired 2 m oil-resistant PVC cable, and a 12 to 24 VDC supply. Ferrous metal is the specified detectable object, with an iron 30 × 30 × 1 mm standard sensing object. Leakage current is 0.8 mA max., response frequency is 0.4 kHz, and differential travel is 15% max. of sensing distance. Red and green indicators show operation and setting status, while IP67 protection is specified. The E2E-X10D1-N is included in inductive proximity sensors from Omron sensing equipment.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2E-X10D1-N 2M |
Omron E2E-X10D1-N 2M Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Inductive |
| Size | M30 |
| Mounting | Shielded |
| Sensing Distance | 10 mm |
| Setting Distance | 0 to 8.0 mm |
| Output Configuration | DC 2 Wire |
| Operation Mode | NO |
| Connection | Pre Wired, Length 2M |
| Cable Specifications | PVC (oil-resistant) |
| Power Supply Voltage | 12 to 24 VDC |
| Body Material | Stainless steel |
| Standard Target | Iron, 30 × 30 × 1 mm |
| Leakage Current | 0.8 mA max |
| Differential Travel | 15% max. of sensing distance |
| Detectable Object | Ferrous metal (The sensing distance decreases with non-ferrous metal.) |
| Response Frequency | 0.4 kHz |
| Indicator | Operation indicator (red) and setting indicator (green) |
| Protection Circuit | Surge suppressor, Load short-circuit protection (for control and diagnostic output) |
| Ambient Temperature Range | Operating: −25 to 70°C, Storage: −40 to 85°C (with no icing or condensation) |
| Ambient Humidity Range | Operating/storage: 35% to 95% (with no condensation) |
| Insulation Resistance | ±10% max. of sensing distance at 23° C in the temperature range of –25° C to 70° C |
| Dielectric Strength | 50 MΩ min. (at 500 VDC) between current-carrying parts and case |
| Vibration Resistance | 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions |
| Shock Resistance | 1,000 m/s2 10 times each in X, Y, and Z directions |
| Voltage Influence | ±1% max. of sensing distance at rated voltage in the rated voltage ±15% range |
| Degree Of Protection | IP67 |
| Weight | Approx. 175 g |
The Omron E2E-X10D1-N 2M Proximity Sensor is an M30 shielded inductive model with a 10 mm sensing distance and a 0 to 8 mm setting distance. It uses a DC 2-wire NO output and a pre-wired 2 m oil-resistant PVC cable, operating from 12 to 24 VDC. Ferrous metal is specified as the detectable object, and the standard sensing object is iron measuring 30 × 30 × 1 mm. Leakage current is 0.8 mA max., response frequency is 0.4 kHz, and differential travel is 15% max. of sensing distance. Red and green indicators provide operation and setting indication. A surge suppressor and load short-circuit protection are specified for the control and diagnostic output.
Operating temperature is -25 to 70°C and storage temperature is -40 to 85°C without icing or condensation, with humidity from 35% to 95%. Temperature influence is ±10% max. of sensing distance at 23°C across -25 to 70°C. Insulation resistance is 50 MΩ min. at 500 VDC, dielectric strength is 1,000 VAC for 1 minute, and voltage influence is ±1% max. within rated voltage ±15%. IP67 protection is listed. For the same M30, 10 mm, DC 2-wire NO sensing configuration in an M12 connector version, see E2E-X10D1-M1G.
