Omron E2B-S08LS02-WP-B1 2M Proximity Sensor
Omron E2B-S08LS02-WP-B1 2M is an M8 shielded cylindrical inductive proximity sensor with a 2 mm sensing distance, a 0 to 1.6 mm setting distance, and long-body construction. It provides a DC 3-wire PNP output with NO operation through a pre-wired 2 m cable and operates from 10 to 30 VDC. Ferrous metal is the specified detectable object, using an 8 × 8 × 1 mm standard sensing object. Response frequency is 1,500 Hz, control output is rated 200 mA max. at 30 VDC max., and voltage drop is 2 V max. A yellow LED indicates operation. The E2B-S08LS02-WP-B1 2M is included under M8 proximity sensors from Omron sensing products.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2B-S08LS02-WP-B1 2M |
Omron E2B-S08LS02-WP-B1 2M Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Inductive |
| Housing Shape | Cylindrical |
| Size | M8 |
| Mounting type | Shielded |
| Sensing Distance | 2 mm |
| Setting Distance | 0 to 1.6 mm |
| Output configuration | DC, 3-wire, PNP |
| Operation Mode | NO |
| Body Length | Long body |
| Connection Method | Pre-wired 2M Cable |
| Detectable Object | Ferrous metal |
| Standard Sensing Object | 8 × 8 × 1 mm |
| Response Frequency | 1,500 Hz |
| Power Supply Voltage | 10 to 30 VDC |
| Protection Circuit | Output reverse polarity protection, Power source circuit reverse polarity protection, Surge suppressor, Short-circuit protection |
| Ambient Temperature Range | Operation and storage : -25 to 70ºC |
| Degree of Protection | IP67(IEC60529), EMC (EN60947-5-2) |
| Control Output | 200 mA max. (30 VDC max.) 2 V max. |
| Indicators | Operation indicator (Yellow LED) |
| Materials | Stainless steel, e PBT, Standard cable is 4 mm dia. PVC. Brass-nickel plated, Zinc-plated iron |
| Weight | Approx. 65 g |
The Omron E2B-S08LS02-WP-B1 2M Proximity Sensor uses an M8 shielded cylindrical inductive sensing body with a 2 mm sensing distance, a 0 to 1.6 mm setting distance, and long-body construction. It provides a DC 3-wire PNP output with NO operation through a pre-wired 2 m cable and operates from 10 to 30 VDC. Ferrous metal is the specified detectable object, with an 8 × 8 × 1 mm standard sensing object. Response frequency is 1,500 Hz. Control output is rated 200 mA max. at 30 VDC max., and the listed voltage drop is 2 V max. A yellow operation LED is provided together with output reverse-polarity protection, power-source reverse-polarity protection, surge suppression, and short-circuit protection.
Operating and storage conditions for the E2B-S08LS02-WP-B1 are -25 to 70°C. IP67 according to IEC 60529 and EMC according to EN60947-5-2 are specified. Stainless steel, PBT, nickel-plated brass, zinc-plated iron, and the standard 4 mm diameter PVC cable are listed among the construction details. The M8 long-body format combines shielded 2 mm sensing with PNP NO switching and the stated pre-wired connection. Ferrous metal remains the specified target for the sensing data. For another long-body E2B sensor with a 2 mm sensing distance but an M12 body, PNP NC output, and M12 connector, see E2B-M12LS02-M1-B2.
