Omron E2EY-X8C1 2M Proximity Sensor
The Omron E2EY-X8C1 2M Proximity Sensor offers Inductive, M30, Shielded, 8 mm Sensing distance, DC 3-wire, NPN NO, Pre-wired 2 M Cable, 12 to 24 VDC Power supply voltage. Manufactured by Omron under the Omron Proximity Sensors category, this model belongs to the Omron E2EY Series.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2EY-X8C1 2M |
Omron E2EY-X8C1 2M Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Inductive |
| Size | M30 |
| Mounting type | Shielded |
| Sensing Distance | 8 mm |
| Setting Distance | 0 to 5.6 mm |
| Output configuration | DC 3-wire, NPN |
| Operation Mode | NO |
| Connection Method | Pre-wired 2 M Cable |
| Detectable Object | Non-ferrous metal |
| Standard Sensing Object | Aluminum: 30 Γ 30 Γ 1 mm |
| Response Frequency | 70 Hz |
| Power Supply Voltage | 12 to 24 VDC |
| Protection Circuit | Reverse polarity protection, Load short-circuit protection, Surge suppressor |
| Ambient Temperature Range | Operating/Storage: β10 to 55Β°C (with no icing or condensation) |
| Degree of Protection | IEC 60529 IP67, in-house standards: oil-resistant |
| Control Output | 100 mA max. (at 30 VDC) |
| Indicators | Detection indicator (red) |
| Materials | Nickel-plated brass, Heat-resistant ABS, Nickel-plated brass, Zinc-plated iron |
| Weight | Approx. 190 g |
The Omron E2EY-X8C1 2M is often compared with other models in the E2EY Aluminum-detecting Proximity Sensor group due to shared installation characteristics and consistent sensing behavior. Engineers frequently evaluate Omron E2EY-X4C1 2M (M18, 4 mm sensing), Omron E2EY-X4C1 2M (M18, 4 mm sensing), and Omron E2EY-X4C1 2M (M18, 4 mm sensing) when selecting suitable alternatives. This ensures compatibility when matching size, sensing distance, wiring style, output logic, or connector format. The E2EY-X8C1 2M integrates smoothly into machinery, fixtures, conveyors, and automation systems requiring dependable detection from an Omron Aluminum-Detecting Proximity Sensor.
