Omron E2B-S08LS02-MC-B1 Proximity Sensor
Omron E2B-S08LS02-MC-B1 is an M8 shielded inductive proximity sensor with a 2 mm sensing distance, 0 to 1.6 mm setting distance, and long-body design. Its PNP output operates in NO mode through a 3-pin M8 connector, with a 10 to 30 VDC supply. Ferrous metal is the specified detectable object, using an 8 × 8 × 1 mm standard sensing object. Response frequency is 1,500 Hz, current consumption is 10 mA max., and differential travel is 10% max. of sensing distance. A yellow operation indicator and IP67 protection are listed. The E2B-S08LS02-MC-B1 is included in shielded proximity sensors from Omron industrial sensing products.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2B-S08LS02-MC-B1 |
Omron E2B-S08LS02-MC-B1 Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Inductive |
| Size | M8 |
| Mounting | Shielded |
| Sensing Distance | 2 mm |
| Setting Distance | 0 to 1.6 mm |
| Body Length | Long body |
| Output Configuration | PNP |
| Operation Mode | NO |
| Connection | M8 Connector (3-pin) |
| Power Supply Voltage | 10 to 30 VDC |
| Body Material | Stainless steel |
| Standard Target | 8 × 8 × 1 mm |
| Differential Travel | 10% max. of sensing distance |
| Detectable Object | Ferrous metal (The sensing distance decreases with non-ferrous metal.) |
| Response Frequency | 1,500 Hz |
| Current Consumption | 10 mA max |
| Indicator | Operation indicator (Yellow LED) |
| Protection Circuit | Output reverse polarity protection, Power source circuit reverse polarity protection, Surge suppressor, Short-circuit protection |
| Ambient Temperature Range | Operation and storage : -25 to 70ºC (with no icing or condensation) |
| Ambient Humidity Range | Operating: 35% to 95%, Storage: 35% to 95% |
| Insulation Resistance | ±10% max. of sensing distance at 23ºC within temperature range of -10 to 55ºC ±15% max. of sensing distance at 23ºC within temperature range of -25 to 70ºC |
| Dielectric Strength | 50 MΩ min. (at 500 VDC) between current carry parts and case |
| Vibration Resistance | 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y and Z directions |
| Shock Resistance | 500 m/s2, 10 times each in X, Y and Z directions |
| Voltage Influence | ±1% max. of sensing distance in 24 V ±15% |
| Degree Of Protection | IP67 |
| Weight | Approx. 20 g |
The Omron E2B-S08LS02-MC-B1 Proximity Sensor is an M8 shielded inductive model with a 2 mm sensing distance, 0 to 1.6 mm setting distance, and long-body construction. It provides a PNP output with NO operation through a 3-pin M8 connector and operates from a 10 to 30 VDC supply. Ferrous metal is listed as the detectable object, with an 8 × 8 × 1 mm standard sensing object. Response frequency is 1,500 Hz, current consumption is 10 mA max., and differential travel is 10% max. of sensing distance. A yellow operation LED is provided, while output reverse-polarity, power-source reverse-polarity, surge, and short-circuit protection are specified.
The E2B-S08LS02-MC-B1 is rated for operation and storage from -25 to 70°C without icing or condensation and for 35% to 95% humidity. Temperature influence is ±10% max. at 23°C from -10 to 55°C and ±15% max. from -25 to 70°C. Insulation resistance is 50 MΩ min. at 500 VDC, dielectric strength is 1,000 VAC for 1 minute, and voltage influence is ±1% max. at 24 VDC ±15%. The stainless-steel case is specified with IP67 protection. For another long-body E2B model using shielded sensing and NO operation but an M12 body with a 4 mm sensing distance, see E2B-M12LS04-M1-C1.
