Omron D5B-5511 Limit Switch
The Omron D5B-5511 Limit Switch offers Wobble stick actuator, 1 m cable length, M5 type. Manufactured by Omron under the Omron Limit Switch category, this model belongs to the D4B Series.
| Brand | Omron |
| Product | Limit Switch |
| Model Number | D5B-5511 |
Omron D5B-5511 Limit Switch β Technical Specifications
| Specification | Value |
|---|---|
| Type | M5 |
| Shape Structure | Touch switches |
| Electrical Ratings | 1 mA at 5 VDC to 30 mA at 30 VDC |
| Load | Resistive load |
| Actuator Detail | Short spring |
| Repeat Accuracy | Short spring |
| Material Housing | Metal |
| Ambient Temperature | Operating: β10Β°C to 70Β°C (with no icing) |
| Ambient Humidity | Operating: 95% max. |
| Shock Resistance | Mechanical: 1,000 m/s2 min. Malfunction: 300 m/s2 min. |
| Degree Of Protection | IP67 |
| Cable Specifications | Oil-resistant cable |
| Insulation Resistance | 100 M⦠min. at 250 VDC between each terminal and ground |
| Cable Length | 1 m |
| Dielectric Strength | 250 VAC, 50/60 Hz for 1 min between terminals of same polarity (TTP) 1,000 VAC, 50/60 Hz for 1 min between current-carrying metal parts and ground (600 VAC for M5 model) |
| Actuator | Wobble stick |
| Vibration Resistance | Malfunction: 10 to 55 Hz, 1.5-mm double amplitude |
| Operating Mechanism | Slow action |
| Operating Speed | 5 to 500 mm/s |
| Operating Frequency | Mechanical: 120 operations/min. Electrical: 60 operations/min |
| Contact Resistance | 700 m⦠max. |
The Omron D5B-5511 is a compact mechanical touch switch featuring a flexible wobble stick actuator and slow-action contacts. Designed for precise detection of light touch or soft object contact, it supports resistive loads from 1 mA at 5 VDC to 30 mA at 30 VDC. Its robust structure includes a short spring mechanism, M5 conduit entry, and a 1-meter oil-resistant cable, making it suitable for space-limited or oil-rich environments.
This model operates reliably at speeds from 5 to 500 mm/s and offers mechanical durability up to 1,000 m/sΒ² shock resistance and IP67 protection for dust and water ingress. It performs stably under vibration (10β55 Hz) and operates in ambient temperatures from β10Β°C to 70Β°C with up to 95% humidity. The D5B-5511 is ideal for light-touch sensing in robotics, compact machinery, and safety applications requiring minimal force actuation and high reliability.
