Omron CP2E-N20DR-D Programmable Logic Controller
The Omron CP2E-N20DR-D Programmable Logic Controller (PLC) offers a compact CPU Units with 20 points, featuring 12 inputs, and 8 Relay outputs for reliable control. With a program capacity of 10K steps and 16K words of data memory, it delivers stable and efficient automation performance. Operating at 24 VDC supply voltage, the unit supports 20.4 to 26.4 VDC operating range, ensuring wide compatibility. Power consumption is 0.17 A at 5 V and 0.06 A at 24 V. Manufactured by Omron, part of the Omron Programmable Logic Controller range, available under the Omron CP2E Series.
| Brand | Omron |
| Product Type | Programmable Logic Controller |
| Model Number | CP2E-N20DR-D |
Omron CP2E-N20DR-D Programmable Logic Controller - Technical Specifications
| Specification | Value |
|---|---|
| Number of points | CPU Units with 20 points |
| Inputs | 12 points |
| Outputs | 8 points |
| Output type | Relay |
| Program capacity | 10K steps (FB capacity: 10K steps) |
| Data memory capacity | 16K words |
| Current consumption 5 VDC | 0.17 A |
| Current consumption 24 VDC | 0.06 A |
| Dimensions (H Γ D Γ W) | 90mm *1 Γ80mm *2 Γ 86mm |
| Supply voltage | 24 VDC |
| Operating voltage range | 20.4 to 26.4 VDC |
| Power consumption | 13W max. |
| Inrush current | 24 VDC, 30A for 20 ms max. for cold start at room temperature |
| Insulation resistance | Not csolated between primary and secondary DC, power supplies |
| Power interrupt time | 2 ms min. |
| Altitude | 2,000 m max |
| Atmosphere | No corrosive gas |
| Ambient humidity | 10% to 90% |
| "Ambient operating temperature" | 20 to 60Β°C |
| Ambient storage temperature | -20 to 75Β°C (excluding battery) |
| Weight | 340g max. |
The CP2E-N20DR-D from Omron delivers reliable performance with a total of 20 I/O pointsβcomprising 12 digital inputs and 8 relay outputs. It is equipped with a program memory of 10K steps and a data memory capacity of 16K words, making it suitable for scalable automation logic. Operating on a 24 VDC supply and accepting voltages from 20.4 to 26.4 VDC, it supports power-efficient installations without compromising control reliability.
Its compact designβ90mm height, 80mm depth, and 86mm widthβmakes it ideal for control panels with limited space. The unit is engineered to withstand industrial conditions, including temperatures from 20 to 60Β°C, humidity up to 90%, and altitudes up to 2,000 meters. With inrush current tolerance of 30A at 24 VDC and a power consumption of 13W max, it ensures consistent operation during system start-ups and load changes.
Engineers trust the CP2E-N20DR-D PLC for its build quality, 2 ms power hold, and compatibility with harsh environments, including areas with no corrosive gases. Built for long-term operation, it supports Omronβs programming standards and is backed by a global support network.
