Omron CJ2H-CPU64-EIP Programmable Logic Controller

The Omron CJ2H-CPU64-EIP PLC CPU Unit combines high-speed processing with built-in EtherNet/IP connectivity for advanced industrial machine-control and networked automation systems. This Programmable Logic Controller supports up to 2,560 I/O points and 40 units across 3 Expansion Racks, providing a scalable architecture for large control systems. It offers a 400K-step program capacity and 832K words of data memory, including 32K words of DM and 32K words of EM across 25 banks. Its 0.016 μs LD instruction execution supports rapid control processing, while EtherNet/IP enables network communication with compatible automation devices. The CJ2H-CPU64-EIP belongs to the PLC range supporting Omron machine automation.

Brand	Omron
Product Type	Programmable Logic Controller
Model Number	CJ2H-CPU64-EIP

Specification	Value
Program capacity	50 K steps
Current Consumption	5 VDC, 0.82 A
Ambient operating temperature	0 to 55°C
Ambient humidity	10% to 90%
Ambient storage temperature	−20 to 70°C
Data memory capacity	160 K words
Logic execution time	0.016 µs
Overhead Processing Time	200 μs
Max. number of expansion units	40 Units
Max. number of local I/O points	2560
Communication port(s)	EtherNet/IP, Ethernet TCP/IP, Serial RS-232C, USB
CPU Unit Dimensions (H × D × W)	90 mm × 65 mm × 80 mm
Weight	280 g
