Omron CJ1W-ID233 Programmable Logic Controller
The Omron CJ1W-ID233 Programmable Logic Controller (PLC) Input Unit provides DC input with 32 input points rated at 24 VDC. Built for Omron PLC applications, it offers stable input processing and high noise resistance. Compact and lightweight, it enhances system scalability and wiring efficiency. Manufactured by Omron, part of the Omron Programmable Logic Controller range, available under the Omron CJ1W Series.
| Brand | Omron |
| Product Type | Programmable Logic Controller |
| Model Number | CJ1W-ID233 |
| Specification | Value |
|---|---|
| Unit type | CJ1 Basic I/O Units |
| Product name | DC Input Units |
| I/O points | 32 inputs (High speed) |
| Input voltage and current | 24 VDC, 4.1 mA |
| Commons | 16 points, 1 common |
| External connection | MIL connector |
| Number of words allocated | 2 words |
| Current consumption (5 V) | 200 mA max |
| ON Voltage/ON Current | 19.0 VDC min./3 mA min. |
| OFF Voltage/OFF Current | 5 VDC max./1 mA max. |
| ON response time | 8.0 ms max. (Can be set to between 0 and 32 in the Setup.) |
| OFF response time | 8.0 ms max. (Can be set to between 0 and 32 in the Setup.) |
| Insulation Resistance | 20 MΞ© min. between external terminals and the GR terminal (100 VDC) |
| Dielectric Strength | 1,000 VAC between the external terminals and the GR terminal for 1 minute at a leakage current of 10 mA max. |
