Multispan SQT-1044-A2-00: Sequential Timer
The Multispan SQT-1044 Timer offers size, input, Upper: 4-Digit, 7-Segment, 0.56β; Lower: 4-Digit, 7-Segment, 0.40β display. Manufactured by Multispan under the Multispan Timer category, this model belongs to the DTT Series.
| Brand | Multispan |
| Product Type | Timer |
| Model Number | SQT-1044-A2-00 |
Multispan Sequential Timer SQT-1044-A2-00 Technical Specifications
| Specification | Value |
|---|---|
| Panel Cutout (mm) | 92 (H) x 92 (W) mm |
| Auxillary Supply | 100-270V AC |
| Display | Upper: 4-Digit, 7-Segment, 0.56β; Lower: 4-Digit, 7-Segment, 0.40β |
| Supply | 100 to 270V AC, 50-60Hz |
| Output | 8 Relay |
| Keys | SET, SHIFT, INC, ENT/RST |
| Rating | 5A, 230V AC |
| Power consumption (VA RATING) | Approx. 5 VA @ 230V AC MAX |
| Operating Temperature | 0Β°C to 55Β°C |
| Relative Humidity | Up to 95% RH (non-condensing) |
| Protection Level (AS Per Request) | IP-65 (Front side) as per IS/IEC 60529: 2001 |
| Range | 99.99 Sec, 999.9 Sec, 99.59 Min, 99.59 Hrs, 999.9 Hrs |
| Timer Mode | Delayed ON, Delayed OFF, Cycle Timer |
| LED Indication | 1. Relay Status 2. Time Unit |
