Multispan PM-11-E3-00 Multifunction Meter
The Multispan PM-11 Multifunction Meter offers 96 (H) x 96 (W) x 54 (D) size, 100 to 270V AC/DC supply, 1Γ-2 Wire input signal. Manufactured by Multispan under the Multispan Multifunction Meter category, this model belongs to the THD & IMP Series.
| Brand | Multispan |
| Product Type | Multifunction Meter |
| Model Number | PM-11-E3-00 |
Multispan PM-11-E3-00 Multifunction Meter - Technical Specifications
| Specification | Value |
|---|---|
| Input Signal | 1Γ-2 Wire |
| CT Primary | UP to 9999A (Programm.) |
| CT Secondary | 5A/1Amp Selectable |
| PF Avg. & Per Phase | 0.100 - 1.000 |
| Frequency (Hz) | 45.0 to 65.0 Hz |
| Display | 4-Digit, 3-Line, 7-Seg, 0.56β Red LED |
| Key | Set, Inc, Dec |
| Supply voltage | 100 to 270V AC/DC, 50/60Hz |
| Accuracy | Class 0.5 (Standard) |
| Relative Humidity | 95 % RH NonCondensing |
| Protection Level | IP-65 (Front side As per IS/IEC 60529 : 2001) |
| Size (mm) | 96 (H) x 96 (W) x 54 (D) |
| Panel Cutout (mm) | 92 (H) x 92 (W) |
| Note | Modbus Available on Request |
| Voltage Network Selection | 1Γ2W |
| Voltage | 30V to 300V AC |
| Current | CT Primary : 5A to 9999A CT Secondary : 5A & 1A Selectable |
| Supply | 100 to 270V AC/DC |
