During technical comparisons, MHC-1101-A2-04 appears alongside Masibus Temperature Controller, Ptc 4202A and Multispan SMPS so engineers assess signal types, ingress protection, and ambient tolerances accurately.
Multispan MHC-1101-A2-04 Temperature Controller
The Multispan MHC-1202 Temperature Controller offers 96x96x54(HxWxD)mm size, 1Relay + 4-20mA Retransmission output, Humidity Sensor (RH-100) input, Upper display, 7-Seg, Red 0.56β LED for Process Value
Lower display, 7-Seg, White 0.56β LED for Process Set Value display. Manufactured by Multispan under the Multispan Temperature Controller category, this model belongs to the TC Series.
| Brand | Multispan |
| Product Type | Temperature Controller |
| Model Number | MHC-1101-A2-04 |
Multispan Temperature Controller MHC-1101-A2-04 Technical Specifications
| Specification | Value |
|---|---|
| Input | Humidity Sensor (RH-100) |
| Output | 1Relay + 4-20mA Retransmission |
| Auxillary Supply | 100-270V AC |
| Size | 96x96x54(HxWxD)mm |
| Outputs | 2Relay 1C/O (On-Off) |
| Protection Level | IP-65 (Front side) As per IS/IEC 60529 : 2001 |
| Input Range | Humidity (0.0 TO 100.0 % RH) |
| Display | Upper display, 7-Seg, Red 0.56β LED for Process Value Lower display, 7-Seg, White 0.56β LED for Process Set Value |
| Panel Cutout (mm) | 92 (H) X 92 (W) |
| Supply | 100 To 270V AC, 50/60 Hz, Approx 4VA |
