Multispan AMP-19-B1-06 Digital Panel Meter
The Multispan AMP-19 Digital Panel Meter offers 230V AC auxiliary, 3-Digit, 3-Line, 7-Seg 0.56”,red LED Display display, 100 to 270V AC,50/60 Hz, Approx 3VA power supply. Manufactured by Multispan under the Multispan Digital Panel Meter category, this model belongs to the AMP Series.
| Brand | Multispan |
| Product Type | Digital Panel Meter |
| Model Number | AMP-19-B1-06 |
Multispan AMP-19-B1-06 Digital Panel Meter - Technical Specifications
| Specification | Value |
|---|---|
| Input Current | 0.5 to 5AMP AC, (PRIMARY) CAT III |
| Display | 3-Digit, 3-Line, 7-Seg 0.56”,red LED Display |
| Size (mm) | 96(H) X 96 (W) X 43 (D) |
| Panel Cutout(mm) | 92 (H) X 92 (W) |
| LED Indication | Kilo Ampere Reading |
| Power Supply | 100 to 270V AC,50/60 Hz, Approx 3VA |
| Operating Temperature | 0°C To 55°C |
| Relative Humidity | Upto 95% RH Non Condensing |
| Protection Level (As per request) | IP-65 (Front side) As per IS/IEC 60529 : 2001 |
| Note | Modbus Available on Request in AMP-13 |
| Current | CT Input: 60A with DIN 60AX CT |
| Auxillary | 230V AC |
