UPort 1200/1400/1600 Series: Moxa 2-16-port RS-232/422/485 Converters
Technical Specifications of Moxa 2 to 16-port RS-232, RS-422/485, and RS-232/422/485 USB-to-serial Converters UPort 1200/1400/1600 Series:
| Speed | 12 Mbps, 480 Mbps |
| USB Connector | USB Type B |
| Flow Control | None, RTS/CTS, XON/XOFF |
| Isolation | 2 kV (I models) |
Moxa 2 to 16-port RS-232, RS-422/485, and RS-232/422/485 USB-to-serial Converters UPort 1200/1400/1600 Series Technical Specifications:
| Specification | Value |
|---|---|
| Speed | 12 Mbps, 480 Mbps |
| USB Connector | USB Type B |
| USB Standards | USB 1.1/2.0 compliant |
| No. of Ports | UPort 1200 Models: 2, UPort 1400 Models: 4, UPort 1600-8 Models: 8, UPort 1600-16 Models: 16 |
| Baudrate | 50 bps to 921.6 kbps |
| Data Bits | 5, 6, 7, 8 |
| Stop Bits | 1, 1.5, 2 |
| Parity | None, Even, Odd, Space, Mark |
| Flow Control | None, RTS/CTS, XON/XOFF |
| Isolation | 2 kV (I models) |
| Input Voltage | UPort 1250/1410/1450: 5 VDC, UPort 1410/1450 Models: 5 V for USB port power, 12 V for external power adapter, UPort 1250I/1400/1600-8 Models: 12 to 48 VDC, UPort 1600-16 Models: 100 to 240 VAC |
| Input Current | UPort 1250: 360 mA @ 5 VDC, UPort 1250I: 200 mA @ 12 VDC, UPort 1410/1450: 260 mA @ 12 VDC, UPort 1450I: 360 mA @ 12 VDC, UPort 1610-8/1650-8: 580 mA @ 12 VDC, UPort 1600-16 Models: 220 mA @ 100 VAC |
| Housing | Metal |
| Dimensions | UPort 1250/1250I: 77 x 26 x 111 mm (3.03 x 1.02 x 4.37 in), UPort 1410/1450/1450I: 204 x 30 x 125 mm (8.03 x 1.18 x 4.92 in), UPort 1610-8/1650-8: 204 x 44 x 125 mm (8.03 x 1.73 x 4.92 in), UPort 1610-16/1650-16: 440 x 45.5 x 198.1 mm (17.32 x 1.79 x 7.80 in) |
| Weight | UPort 1250/1250I: 180 g (0.40 lb), UPort 1410/1450/1450I: 720 g (1.59 lb), UPort 1610-8/1650-8: 835 g (1.84 lb), UPort 1610-16/1650-16: 2,475 g (5.45 lb) |
| Operating Temperature | UPort 1200 Models: 0 to 60°C (32 to 140°F), UPort 1400//1600-8/1600-16 Models: 0 to 55°C (32 to 131°F) |
| EMC | EN 55032/35 |
Get A Quote for Moxa 2 to 16-port RS-232, RS-422/485, and RS-232/422/485 USB-to-serial Converters UPort 1200/1400/1600 Series at the best price. Here are the brief Technical Specifications of UPort 1200/1400/1600 Series are speed of up to 12 Mbps, 480 Mbps. These sensors are equipped with USB Type B connectors, providing flexible connectivity options. Supporting a wide baud rate range from 50 bps to 921.6 kbps, the sensors include flow control options such as None, RTS/CTS, XON/XOFF ensuring reliable data transmission. Built with 2 kV (I models) isolation (available in I models) for enhanced protection, they operate on a UPort 1250/1410/1450: 5 VDC, UPort 1410/1450 Models: 5 V for USB port power, 12 V for external power adapter, UPort 1250I/1400/1600-8 Models: 12 to 48 VDC, UPort 1600-16 Models: 100 to 240 VAC input voltage, making them suitable for various industrial applications. The housing materials are robust, with the Metal. It's Time to get a Quote for your requirement of Moxa 2 to 16-port RS-232, RS-422/485, and RS-232/422/485 USB-to-serial Converters. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
