MiiNePort E1 Series: Moxa 10/100 Mbps Serial Device Server Module
Technical Specifications of Moxa 10/100 Mbps Embedded Drop-in Module Serial Device Servers MiiNePort E1 Series:
| CPU | 32-bit Arm Core |
| Flash | 2 MB |
| Data Bits | 5, 6, 7, 8 |
| Input Voltage | 3.3 VDC |
Moxa 10/100 Mbps Embedded Drop-in Module Serial Device Servers MiiNePort E1 Series Technical Specifications:
| Specification | Value |
|---|---|
| CPU | 32-bit Arm Core |
| Flash | 2 MB |
| SDRAM | 4 MB |
| Digital Input Channels | 1 |
| Digital Output Channels | 1 |
| 10/100BaseT(X) Ports, Auto MDI/MDI-X | 8-pin RJ45 |
| Magnetic Isolation Protection | 1.5 kV (built-in) |
| Configuration Options | Web Console (HTTP), Windows Utility, Telnet Console, Serial Console |
| Management | ARP, BOOTP, Device Search Utility (DSU), DHCP Client, HTTP, IPv4, SMTP, SNMPv1, TCP/IP, Telnet, TFTP, ICMP |
| No. of Ports | 1 |
| Baudrate | MiiNePort E1 Series: 50 bps to 230.4 kbps, MiiNePort E1-H/-SDK Series: 50 bps to 921.6 kbps |
| Data Bits | 5, 6, 7, 8 |
| Stop Bits | 1, 1.5, 2 |
| Parity | None, Even, Odd, Space, Mark |
| Input Voltage | 3.3 VDC |
| Operating Temperature | Standard models: 0 to 55˚C (32 to 131˚F), Wide Temp. models: -40 to 85˚C (-40 to 185˚F), 0 to 55°C (32 to 131°F) |
| EMC | EN 55032/35 |
| Shock | IEC 60068-2-27 |
| Warranty Period | 5 years |
IndMALL Automation Dealing offers Moxa 10/100 Mbps Embedded Drop-in Module Serial Device Servers MiiNePort E1 Series at unbeatable prices. The Main Technical Parameters of MiiNePort E1 Series are 32-bit Arm Core CPU, featuring 2 MB Flash memory and 4 MB SDRAM for efficient processing and storage. Equipped with 8-pin RJ45 10/100BaseT(X) ports, these sensors support Auto MDI/MDI-X and provide 1.5 kV (built-in) magnetic isolation protection. Configuration options include a Web Console (HTTP), Windows Utility, Telnet Console, Serial Console and serial console, offering versatile setup and management. The sensors support baud rates from MiiNePort E1 Series: 50 bps to 230.4 kbps, MiiNePort E1-H/-SDK Series: 50 bps to 921.6 kbps with data bits of 5, 6, 7, 8 and stop bits of 1, 1.5, 2. Parity options include None, Even, Odd, Space, Mark ensuring flexible communication protocols. Operating on an input voltage of 3.3 VDC the sensors are designed to perform reliably in temperatures ranging from Standard models: 0 to 55˚C (32 to 131˚F), Wide Temp. models: -40 to 85˚C (-40 to 185˚F), 0 to 55°C (32 to 131°F). Take the First Step with a Quote for your requirement of Moxa 10/100 Mbps Embedded Drop-in Module Serial Device Servers. Choose us for unparalleled pricing and support over other Dealers & Distributors.
