MGate 5192 Series: Moxa 1-port IEC 61850-to-DNP3/101/104/Modbus
Technical Specifications of Moxa 1-port IEC 61850-to-DNP3/101/104/Modbus MGate 5192 Series:
| Security Protocols | SNMPv3, SNMPv2c Trap, HTTPS (TLS 1.3) |
| Input Voltage | 12 to 48 VDC |
| Power Connector | Spring-type Euroblock terminal |
| IP Rating | IP30 |
Moxa 1-port IEC 61850-to-DNP3/101/104/Modbus MGate 5192 Series Technical Specifications:
| Specification | Value |
|---|---|
| 10/100BaseT(X) Ports (RJ45 connector) | 2, Auto MDI/MDI-X connection |
| Industrial Protocols | Modbus RTU/ASCII Server, IEC 60870-5-101 Server, DNP3 Serial Outstation |
| Management | ARP, DHCP Client, DNS, HTTP, HTTPS, SMTP, SNMP Trap, SNMPv1/v2c/v3, TCP/IP, UDP |
| Time Management | NTP Client |
| Security Protocols | SNMPv3, SNMPv2c Trap, HTTPS (TLS 1.3) |
| Serial Standards | RS-232/422/485 |
| Baudrate | 300 bps to 921.6 kbps |
| Isolation | 2 kV (built-in) |
| RS-232 | TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND |
| RS-422 | Tx+, Tx-, Rx+, Rx-, GND |
| RS-485-2w | Data+, Data-, GND |
| RS-485-4w | Tx+, Tx-, Rx+, Rx-, GND |
| Input Voltage | 12 to 48 VDC |
| Power Connector | Spring-type Euroblock terminal |
| IP Rating | IP30 |
| Operating Temperature | -40 to 75°C (-40 to 167°F) |
| EMC | EN 61000-6-2/-6-4 |
| Shock | IEC 60068-2-27 |
| Vibration | IEC 60068-2-6, IEC 60068-2-64 |
| Warranty Period | 5 years |
IndMALL Automation Dealing offers Moxa 1-port IEC 61850-to-DNP3/101/104/Modbus MGate 5192 Series at unbeatable prices. The Main Technical Parameters of MGate 5192 Series are 2, Auto MDI/MDI-X connection 10/100BaseT(X) ports (RJ45 connectors), ensuring seamless network integration. These switches support industrial protocols such as Modbus RTU/ASCII Server, IEC 60870-5-101 Server, DNP3 Serial Outstation, making them versatile for various industrial applications. Time management is handled through an NTP Client, ensuring precise time synchronization across your network. Security is robust, with protocols like SNMPv3, SNMPv2c Trap, HTTPS (TLS 1.3) providing secure communication. The switches operate on a wide input voltage range of 12 to 48 VDC, and are equipped with a Spring-type Euroblock terminal for reliable power connections. With an IP30 rating, they are protected against dust and operate efficiently in extreme temperatures ranging from -40 to 75°C (-40 to 167°F). Take the First Step with a Quote for your requirement of Moxa 1-port IEC 61850-to-DNP3/101/104/Modbus. Choose us for unparalleled pricing and support over other Dealers & Distributors.
