EDS-505A Series: Moxa 5-port Managed Ethernet Switches
Technical Specifications of Moxa 5-port Managed Ethernet Switches EDS-505A Series:
| IGMP Groups | 256 |
| Max. No. of VLANs | 64 |
| Packet Buffer Size | 1 Mbits |
| Priority Queues | 4 |
Moxa 5-port Managed Ethernet Switches EDS-505A Series Technical Specifications:
| Specification | Value |
|---|---|
| 10/100BaseT(X) Ports (RJ45 connector) | EDS-505A/505A-T: 5, EDS-505A-MM-SC/MM-ST/SS-SC Series: 3, All models support:, Auto negotiation speed, Full/Half duplex mode, Auto MDI/MDI-X connection |
| 100BaseFX Ports (multi-mode SC connector) | EDS-505A-MM-SC Series: 2 |
| 100BaseFX Ports (single-mode SC connector) | EDS-505A-SS-SC Series: 2 |
| Management | IPv4/IPv6, SNMPv1/v2c/v3, LLDP, Port Mirror, Back Pressure Flow Control, BOOTP, DDM, DHCP Option 66/67/82, DHCP Server/Client, Flow control, RARP, RMON, SMTP, SNMP Inform, Syslog, Telnet, TFTP |
| MIB | MIB-II, Bridge MIB, Ethernet-like MIB, P-BRIDGE MIB, Q-BRIDGE MIB, RMON MIB Groups 1, 2, 3, 9, RSTP MIB |
| Redundancy Protocols | STP, MSTP, RSTP, LACP, Link Aggregation, Turbo Chain, Turbo Ring v1/v2 |
| Time Management | NTP Server/Client, SNTP |
| IGMP Groups | 256 |
| MAC Table Size | 8 K |
| Max. No. of VLANs | 64 |
| Packet Buffer Size | 1 Mbits |
| Priority Queues | 4 |
| VLAN ID Range | VID 1 to 4094 |
| Input Voltage | 12/24/48 VDC, Redundant dual inputs |
| Operating Temperature | Standard Models: -10 to 60°C (14 to 140°F), Wide Temp. Models: -40 to 75°C (-40 to 167°F) |
| EMC | EN 55032/35 |
Ask for the Pricing of Moxa 5-port Managed Ethernet Switches EDS-505A Series at unbeatable prices. Detailed Specifications of EDS-505A Series features 256 IGMP groups and a maximum of 64 VLANs. The sensors include a 1 Mbits packet buffer size, ensuring efficient data handling even in high-traffic environments. With 4 priority queues, they prioritize critical data for smooth network performance. The VLAN ID range spans from VID 1 to 4094, allowing extensive network segmentation and control. These sensors operate on a versatile input voltage range of 12/24/48 VDC, Redundant dual inputs. Now's the Time to Secure a Quote for your requirement of Moxa 5-port Managed Ethernet Switches. We're committed to offering more favorable pricing and more responsive support than other Traders.
