EDS-208A Series: Moxa 8-port Compact Unmanaged Ethernet Switches
Technical Specifications of Moxa 8-port Compact Unmanaged Ethernet Switches EDS-208A Series:
| Dimensions | 50 x 114 x 70 mm (1.96 x 4.49 x 2.76 in) |
| Installation | DIN-rail mounting, Wall mounting (with optional kit) |
| Input Voltage | 12/24/48 VDC, Redundant dual inputs |
| Housing | Aluminum |
Moxa 8-port Compact Unmanaged Ethernet Switches EDS-208A Series Technical Specifications:
| Specification | Value |
|---|---|
| 10/100BaseT(X) Ports (RJ45 connector) | EDS-208A/208A-T Models: 8, EDS-208A-M-SC/M-ST/S-SC Models: 7, EDS-208A-MM-SC/MM-ST/SS-SC Models: 6, All Models Support:, Auto negotiation speed, Full/Half duplex mode, Auto MDI/MDI-X connection |
| Standards | Telcordia (Bellcore), GB |
| MAC Table Size | 2 K |
| Packet Buffer Size | 768 kbits |
| Input Voltage | 12/24/48 VDC, Redundant dual inputs |
| Overload Current Protection | Supported |
| Reverse Polarity Protection | Supported |
| Dimensions | 50 x 114 x 70 mm (1.96 x 4.49 x 2.76 in) |
| Installation | DIN-rail mounting, Wall mounting (with optional kit) |
| Housing | Aluminum |
| Operating Temperature | Standard Models: -10 to 60°C (14 to 140°F), Wide Temp. Models: -40 to 75°C (-40 to 167°F) |
| EMC | EN 55032/35 |
| Warranty Period | 5 years |
| IP Rating | IP30 |
| Hazardous Locations | ATEX, Class I Division 2 |
| Maritime | ABS, LR, NK, DNV |
Obtain a Quote for Moxa 8-port Compact Unmanaged Ethernet Switches EDS-208A Series at economical prices. The EDS-208A Series Datasheet provides an overview of key specifications, including Telcordia (Bellcore) and GB standards, ensuring reliable performance in industrial environments. These switches feature a 2 K MAC table size and a packet buffer size of 768 kbits, providing efficient data handling capabilities. Operating on an input voltage of 12/24/48 VDC with redundant dual inputs, they are equipped with reverse polarity protection, ensuring robust operation and safety. Installation is versatile, with options for DIN-rail mounting or wall mounting (with optional kit). The housing is constructed from durable aluminum, designed to withstand harsh conditions. Compliance with EMC standards EN 55032/35.
Get the EDS-208A Series Price and EDS-208A Series Manual today. Our commitment to better pricing and exceptional support sets us apart from other competitors.
