Movella MTi-320: Inertial Sensor Modules
Technical Specifications of Movella Inertial Sensor Modules MTi-320:
| Roll, pitch | 0.5 deg RMS |
| Dimensions | 28 × 31.5 × 13 mm |
| Input voltage | 4.5 to 24 V |
| Power consumption (typ.) | 300 mW |
Movella Inertial Sensor Modules MTi-320 Technical Specifications
| Specification | Value |
|---|
| Roll, pitch | 0.5 deg RMS |
| Yaw/heading | unreferenced, low drift |
| Position | Strapdown integration (SDI):
Yes |
| Gyroscope Standard full range | 2000 deg/s |
| Accelerometer Standard full range | 16 g |
| IP-rating (equivalent) | IP51 |
| Dimensions | 28 × 31.5 × 13 mm |
| Input voltage | 4.5 to 24 V |
| Power consumption (typ.) | 300 mW |
| Interfaces | RS232 |
| Protocols | Xbus |
| Output frequency | up to 1 kHz, 100 Hz SDI |
| Weight | 9 g |
