Mitsubishi NZ2GNS12A2-16DTE - Programmable Logic Controller
The Mitsubishi NZ2GNS12A2-16DTE Programmable Logic Controller (PLC) offers advanced I/O capabilities for precise control in compact automation systems. This Mitsubishi PLC is ideal for industrial engineers seeking efficient and scalable control solutions.
| Brand | Mitsubishi |
| Product Type | PLC(Programmable Logic Controller) |
| Product | NZ2GNS12A2-16DTE |
Technical Specifications of Mitsubishi Programmable Logic Controller NZ2GNS12A2-16DTE
| Specification | Value |
|---|---|
| Series | CC-LINK IE TSN |
| Type | SAFETY REMOTE I/O COMBINED M. |
| Weight (kg) | 0,52 |
| Power Supply (V) | 24 |
| Current Type | DC |
| Output Type | TRANSISTOR |
| Output Logic | SOURCE + SOURCE |
| Rated Load Voltage (VDC) | 24 |
| Wiring | M12 |
| Int. Current Consumption (A) | 0,26 |
| Rated Input Voltage (VDC) | 24 |
The Mitsubishi NZ2GNS12A2-16DTE PLC, part of the CC-LINK IE TSN series, integrates both safety and standard I/O functions in a single SAFETY REMOTE I/O COMBINED MODULE. It uses transistor outputs with SOURCE + SOURCE logic, enabling compatibility with a wide range of sensors and actuators. Designed for 24V DC operation, the unit consumes just 0.26 A, making it efficient for continuous industrial use. The PLC supports a rated load voltage of 24V DC and delivers a nominal output current of 2.4 A, suitable for controlling motors up to 0.55 hp (0.37 kW).
For network communication, the controller features 1 RJ45 connector and a 2-wire RS 485 interface, ensuring stable, low-noise signal transmission across automation lines. The M12 connector wiring simplifies installation in safety-rated systems, especially where clean, sealed connections are required. Though compact in design, its enclosure complies with IP20 protection and includes EMC filtering to protect against electrical interference. It supports 50/60 Hz ±5% power systems and operates within a wide ambient temperature range of -10°C to 60°C, with derating above 40°C for thermal stability.
With a maximum switching frequency of 16 kHz and nominal at 4 kHz, the NZ2GNS12A2-16DTE delivers fast and accurate control in dynamic load environments. The device is vibration-resistant according to IEC 60068-2-6 and supports natural cooling with only 27 W of heat dissipation. Trusted by OEMs and control engineers across various industries, this Mitsubishi PLC offers high-speed I/O, rugged performance, and seamless integration into MELSEC automation systems.
The Mitsubishi NZ2GNS12A2-16DTE PLC is ideal for applications that require compact yet powerful automation control with integrated safety. It is especially useful in sectors like automotive assembly, bottling lines, robotics-based pick-and-place systems, and food-grade machinery where precision and safety must go hand-in-hand.
With its 24V transistor outputs and SOURCE logic, this PLC allows for reliable switching of output devices such as indicators, relays, actuators, and interlock systems. In Indian factory setups where dust, wiring complexity, or temperature variability are challenges, the M12 connectors simplify structured wiring while protecting signal integrity. It performs well even in high-vibration zones or control panels with limited ventilation, thanks to its fanless design and thermal derating support.
Whether used in machine retrofitting or new equipment design, the Mitsubishi NZ2GNS12A2-16DTE PLC gives system integrators confidence in safety compliance, rapid deployment, and future scalability. With seamless support for MELSEC protocols and GX Works3 software, engineers can rapidly configure and troubleshoot systems while ensuring adherence to international standards.
