Mitsubishi NZ2GN2B1-32DT - Programmable Logic Controller
The Mitsubishi NZ2GN2B1-32DT Programmable Logic Controller (PLC) delivers high-performance digital I/O control, ideal for complex automation systems. Built by Mitsubishi, this PLC is engineered for demanding industrial environments with network-ready connectivity.
| Brand | Mitsubishi |
| Product Type | PLC(Programmable Logic Controller) |
| Product | NZ2GN2B1-32DT |
Technical Specifications of Mitsubishi Programmable Logic Controller NZ2GN2B1-32DT
| Specification | Value |
|---|---|
| Series | CC-LINK IE TSN |
| Type | REMOTE I/O COMBINED MODULE |
| Integrated Digital Inputs | 16 |
| Depth (mm) | 57 |
| Weight (kg) | 0,31 |
| Width (mm) | 200 |
| Height (mm) | 54,5 |
| Power Supply (V) | 24 |
| Current Type | DC |
| Integrated Digital Outputs | 16 |
| Output Type | TRANSISTOR |
| Output Logic | SINK |
| Rated Load Voltage (VDC) | 24 |
| Wiring | SCREW |
| Int. Current Consumption (A) | 0,11 |
| Rated Input Voltage (VDC) | 24 |
| Occupied Stations | 1 |
The Mitsubishi NZ2GN2B1-32DT PLC combines both digital input and output in a single compact unit, offering significant panel space savings while maintaining industrial-grade performance. It features 16 DC digital inputs and 16 transistor outputs with sink logic, making it ideal for fast-response control tasks. With a rated load voltage of 24 VDC and a nominal output current of 2.4 A, it ensures stable performance even during high-frequency switching. The unit supports a switching frequency from 2 to 16 kHz (default 4 kHz), allowing tailored tuning based on load types and performance needs.
Compactly built with dimensions of 200 mm width, 54.5 mm height, and 57 mm depth, and weighing only 0.31 kg, the NZ2GN2B1-32DT is perfect for DIN rail-mounted control panels. The RJ45 Ethernet port and 2-wire RS485 interface ensure easy integration into CC-LINK IE TSN networks, enabling real-time data communication across machines and systems. Designed for long-term reliability, it supports continuous operation in environments from -10°C to 60°C, with derating applied above 40°C. The module meets IEC 60068-2-6 vibration standards, comes with built-in EMC filters, and operates on a wide supply voltage range of 200–240 VAC. Power-efficient with a natural dissipation of just 27 W, this Mitsubishi PLC is trusted in factory automation, machine tool control, and distributed I/O systems.
The Mitsubishi NZ2GN2B1-32DT PLC is widely used in smart factory systems where both input signals (like sensors, push buttons) and output actions (like relays, alarms, indicators) must be managed from one compact controller. It is commonly found in material handling systems, CNC machines, packaging lines, and energy monitoring panels.
For Indian maintenance engineers, this module simplifies cabinet design and reduces wiring effort by combining I/O into a single footprint. The rugged build, wide voltage compatibility, and stable operation in dusty or vibrating environments make it ideal for challenging plant floors. The screw-type terminal connection also makes it easy for junior technicians to wire and test during maintenance or installation phases.
Engineering students will appreciate how the Mitsubishi NZ2GN2B1-32DT fits into real-world distributed I/O systems with minimal latency and high-speed control over Ethernet. It provides hands-on exposure to next-gen PLC technologies like CC-LINK IE TSN, helping them bridge the gap between textbooks and live industrial projects. Whether it’s for motor control, conveyor sequencing, or signal processing, this Mitsubishi PLC delivers unmatched value and control reliability.
