Mitsubishi NZ2GN12A2-16TE - Programmable Logic Controller
The Mitsubishi NZ2GN12A2-16TE Programmable Logic Controller (PLC) is engineered to deliver reliable control and fast data communication in distributed automation systems. Ideal for compact setups, this Mitsubishi PLC ensures precision and network-ready performance.
| Brand | Mitsubishi |
| Product Type | PLC(Programmable Logic Controller) |
| Product | NZ2GN12A2-16TE |
Technical Specifications of Mitsubishi Programmable Logic Controller NZ2GN12A2-16TE
| Specification | Value |
|---|---|
| Series | CC-LINK IE TSN |
| Type | REMOTE TRANSISTOR OUTPUT |
| Depth (mm) | 37,5 |
| Weight (kg) | 0,41 |
| Width (mm) | 63 |
| Height (mm) | 238 |
| Power Supply (V) | 24 |
| Current Type | DC |
| Integrated Digital Outputs | 16 |
| Output Type | TRANSISTOR |
| Output Logic | SOURCE |
| Rated Load Voltage (VDC) | 12-24 |
| Wiring | CONNECTOR |
| Int. Current Consumption (A) | 0,11 |
| Occupied Stations | 1 |
The Mitsubishi NZ2GN12A2-16TE is a compact yet powerful PLC built for high-speed control and stable communication in demanding industrial environments. As part of the CC-LINK IE TSN series, this model is tailored for decentralized systems requiring fast, synchronized signal transmission. It supports 16 integrated digital outputs using source-type transistor logic, operating at a rated load voltage of 12β24 VDC, with a steady nominal output current of 2.4 A.
The unit is equipped with a RJ45 Ethernet connector and a 2-wire RS 485 interface, allowing for high-speed, reliable communication across field-level devices. Its efficient current consumption of just 0.11 A ensures energy-conscious performance, while the switching frequency range of 2 to 16 kHz (default at 4 kHz) provides signal flexibility for diverse control strategies. The controller also supports 2 discrete outputs and 1 analog output, delivering I/O versatility in safety and process control applications.
Designed for cabinet mounting, the NZ2GN12A2-16TE operates reliably between -10Β°C and 60Β°C, with derating considerations beyond 40Β°C for extended thermal resilience. It complies with IEC 60068-2-6 vibration standards and features an IP20 protection rating, ensuring long-term performance in factory environments. With a net weight of 0.7 kg and compact dimensions of 63 mm (W) Γ 238 mm (H) Γ 37.5 mm (D), it is easy to integrate into space-constrained control panels.
Operating on a rated supply voltage of 200β240 V (with a -15% to +10% tolerance) at 50/60 Hz, the unit accommodates global industrial standards. Its low natural power dissipation of 27.0 W makes it an energy-efficient choice for continuous automation tasks. Trusted for its balance of speed, durability, and I/O capability, the Mitsubishi NZ2GN12A2-16TE PLC is an essential part of modern control system architectures.
The Mitsubishi NZ2GN12A2-16TE PLC is ideally suited for high-speed, real-time applications such as robotic control stations, packaging automation lines, material sorting systems, and intelligent conveyor networks. It offers reliable source-type output logic, enabling direct control of relays, solenoids, and motor drivers across decentralized factory layouts.
Maintenance engineers across Indian industries favor this model for its compact size, low heat generation, and simplified panel integration. The use of RS485 and RJ45 connectivity helps reduce wiring complexity and supports easy expansion. Engineering students and junior technicians benefit from understanding transistor-based output control, modular PLC architecture, and network-based signal distribution using this real-world unit.
Whether implemented in high-speed automation lines or as part of a scalable modular control strategy, the Mitsubishi NZ2GN12A2-16TE PLC provides the speed, reliability, and communication integrity required for modern industrial automation. This PLC is a future-ready solution trusted by OEMs and plant engineers alike.
