Mitsubishi NZ2GFS12A2-14DT - Programmable Logic Controller
The Mitsubishi NZ2GFS12A2-14DT Programmable Logic Controller (PLC) is a robust solution designed for decentralized industrial control applications. This high-performance Mitsubishi model ensures reliable automation for engineers seeking efficiency and scalability.
| Brand | Mitsubishi |
| Product Type | PLC(Programmable Logic Controller) |
| Product | NZ2GFS12A2-14DT |
Technical Specifications of Mitsubishi Programmable Logic Controller NZ2GFS12A2-14DT
| Specification | Value |
|---|---|
| Series | CC-LINK IE FIELD NETWORK |
| Type | SAFETY REMOTE I/O COMBINED M. |
| Integrated Digital Inputs | 12/6 |
| Depth (mm) | 48,5 |
| Weight (kg) | 0,89 |
| Width (mm) | 60 |
| Height (mm) | 235 |
| Power Supply (V) | 24 |
| Current Type | DC |
| Integrated Digital Outputs | 2 |
| Output Type | TRANSISTOR |
| Output Logic | SOURCE+SINK |
| Rated Load Voltage (VDC) | 24 |
| Wiring | CONNECTOR |
| Int. Current Consumption (A) | 0,19 |
| Rated Input Voltage (VDC) | 24 |
| Occupied Stations | 1 |
The Mitsubishi NZ2GFS12A2-14DT stands out in the CC-LINK IE FIELD NETWORK series for combining robust safety features with compact performance. Designed as a Safety Remote I/O Combined Module, this PLC integrates 12 digital inputs and 2 digital outputs along with sourcing and sinking logic, allowing dual-mode control to support a wider variety of field devices. It runs on a reliable 24V DC power supply, with a rated input and output voltage of 24VDC, ensuring consistency in signal management.
With dimensions of just 60 mm width, 235 mm height, and 48.5 mm depth, and a body weight of 0.89 kg, this PLC provides significant I/O capabilities while minimizing panel footprint. It draws a modest 0.19 A internal current and operates efficiently on a voltage range of 200β240V AC Β±10%. The controller supports a motor power of 0.55 hp (0.37 kW) and offers a nominal output current of 2.4 Aβsuitable for motion and actuator control tasks in compact systems.
Connectivity is enabled via an RJ45 Ethernet port and 2-wire RS485 interface, providing smooth integration with both central PLCs and distributed safety modules. The unit performs reliably at ambient temperatures from -10Β°C to 40Β°C, extendable up to 60Β°C with derating, and is compliant with IEC 60068-2-6 vibration standards. The adjustable switching frequency range of 2β16 kHz supports customized response rates. Its IP20-rated enclosure, cabinet-mount format, and natural power dissipation of 27.0 W make it installation-ready and maintenance-friendly for system integrators.
Built with safety, flexibility, and reliability in mind, the Mitsubishi NZ2GFS12A2-14DT PLC is a trusted choice for control panels requiring precision input/output processing and communication stability.
The Mitsubishi NZ2GFS12A2-14DT PLC is widely used in conveyor safety zones, robotic arm isolation, and decentralized factory automation where safety I/O modules must function seamlessly within distributed networks. Its combination of sourcing and sinking output logic provides engineers the flexibility to design mixed-signal systems with accurate switching and protection features.
Maintenance engineers in India benefit from its compact design, easy cabinet integration, and RJ45 connectivity, which reduces diagnostic and wiring time. For diploma students and junior automation engineers, this PLC serves as an excellent example of combining safety compliance with I/O control, making it a teaching tool for both logic programming and industrial safety standards.
Whether you're automating a multi-station process line or building safety-driven control panels, the Mitsubishi NZ2GFS12A2-14DT PLC offers the reliability, performance, and communication needed to run efficient, smart, and secure manufacturing systems.
