Mitsubishi HG-SR5024B - Servo Motors
The Mitsubishi HG-SR5024B Servo Motor delivers 5 kW capacity, 23.9 Nm torque, and 2000 rpm speed for industrial drive applications. This model is part of the Mitsubishi servo family, accessible at mitsubishi electric, and features medium inertia, 22-bit encoder, 4194304 p/rev resolution, and IP67 protection. Buyers can review Mitsubishi servo motor ranges at mitsubishi electric with compatibility across systems built on the MELSERVO-J4 series supporting precise motion control needs.
| Brand | Mitsubishi |
| Product Type | Servo Motors |
| Product | HG-SR5024B |
Mitsubishi Servo Motors HG-SR5024B Technical Specifications:
| Specification | Value |
|---|---|
| Series | MELSERVO-J4 |
| Type | HG-SR |
| Power Supply (V) | 400 |
| Rated Capacity (kW) | 5 |
| Inertia | MEDIUM INERTIA |
| Rated Torque (Nm) | 23,9 |
| Maximum Torque (Nm) | 71,6 |
| Rated Speed (rpm) | 2000 |
| Inertia (kg*cm2) | 109 |
| Brake | YES |
| Shaft Type | STRAIGHT SHAFT |
| Current Type | AC |
| Encoder Resolution (p/rev) | 4194304 |
| Maximum Speed (rpm) | 3000 |
| Protection Class | IP67 |
| Encoder Type | 22-BIT |
| Depth (mm) | 307 |
| Weight (kg) | 26 |
| Width (mm) | 176 |
| Height (mm) | 228,9 |
The Mitsubishi HG-SR5024B Servo Motor is a medium inertia 5 kW unit designed for controlled motion in industrial automation systems. The model provides 23.9 Nm torque, 2000 rpm rated speed, and a 22-bit encoder for high-resolution feedback. Part of the MELSERVO-J4 series, the HG-SR5024B supports stable positioning and consistent rotational output across demanding applications.
This servo motor is suitable for conveyors, packaging lines, assembly machinery, and process equipment requiring reliable torque delivery. Its 3000 rpm maximum speed, AC operation, and IP67 construction allow it to perform effectively in production environments with mechanical loads, vibration, or exposure to dust and moisture. The built-in brake supports machines that require holding torque during stopped or powered-off conditions.
The Mitsubishi HG-SR5024B Servo Motor combines precise encoder feedback, consistent torque performance, and durable protection suitable for industrial use. Mitsubishiβs engineering reliability reinforces the model's capability to integrate into automation frameworks that depend on predictable operation, long service life, and stable machine movement.
