Mitsubishi HG-KR23K - Servo Motors
The Mitsubishi HG-KR23K Servo Motor provides 0.2 kW capacity, 0.64 Nm torque, and 3000 rpm rated speed for low inertia applications. It operates on a 200 V AC supply, uses a keyway shaft, and supports a maximum speed of 6000 rpm. The motor includes a 22-bit encoder with 4194304 pulses per revolution and an IP65 protection rating. For brand details visit Mitsubishi, explore Mitsubishi Servo Motors, and view its placement in the MELSERVO-J4 series.
| Brand | Mitsubishi |
| Product Type | Servo Motors |
| Product | HG-KR23K |
Mitsubishi Servo Motors HG-KR23K Technical Specifications:
| Specification | Value |
|---|---|
| Series | MELSERVO-J4 |
| Type | HG-KR |
| Power Supply (V) | 200 |
| Rated Capacity (kW) | 0,2 |
| Inertia | LOW INERTIA |
| Rated Torque (Nm) | 0,64 |
| Maximum Torque (Nm) | 2,2 |
| Rated Speed (rpm) | 3000 |
| Inertia (kg*cm2) | 221 |
| Brake | NO |
| Shaft Type | KEYWAY |
| Current Type | AC |
| Encoder Resolution (p/rev) | 4194304 |
| Maximum Speed (rpm) | 6000 |
| Protection Class | IP65 |
| Encoder Type | 22-BIT |
| Depth (mm) | 76,6 |
| Weight (kg) | 0,91 |
| Width (mm) | 60 |
| Height (mm) | 77,1 |
The Mitsubishi HG-KR23K Servo Motor is a low inertia model designed for compact and precise motion applications in industrial automation. It delivers 0.2 kW output capacity, generates 0.64 Nm rated torque, and runs at a rated speed of 3000 rpm. As part of the MELSERVO-J4 series, it uses a 22-bit encoder for accurate feedback and supports stable operation with AC supply.
This model is suitable for conveyors, light-duty packaging machines, pick-and-place units, and assembly mechanisms that require smooth acceleration and consistent positioning. The keyway shaft ensures secure torque transmission, while IP65 protection helps maintain reliable operation in dust and light moisture environments. Its high encoder resolution supports repeatable and stable automation performance.
The Mitsubishi HG-KR23K Servo Motor combines precise encoder feedback, steady torque delivery, and consistent speed control for demanding motion tasks. With its MELSERVO-J4 platform and 200 V AC compatibility, the motor offers dependable operation across various machine automation needs. Engineers can rely on this model for accurate, durable, and consistent performance in continuous industrial use.
