Mitsubishi HG-JR7034B - Servo Motors
Technical Specifications of Mitsubishi Servo Motors HG-JR7034B:
| Brand | Mitsubishi |
| Product Type | Servo Motors |
| Product | HG-JR7034B |
Mitsubishi Servo Motors HG-JR7034B Technical Specifications:
| Specification | Value |
|---|---|
| Series | MELSERVO-J4 |
| Type | HG-JR |
| Power Supply (V) | 400 |
| Rated Capacity (kW) | 7 |
| Inertia | LOW INERTIA |
| Rated Torque (Nm) | 22,3 |
| Maximum Torque (Nm) | 66,8 |
| Rated Speed (rpm) | 3000 |
| Inertia (kg*cm2) | 52,9 |
| Brake | YES |
| Shaft Type | STRAIGHT SHAFT |
| Current Type | AC |
| Encoder Resolution (p/rev) | 4194304 |
| Maximum Speed (rpm) | 5000 |
| Protection Class | IP67 |
| Encoder Type | 22-BIT |
| Depth (mm) | 392 |
| Weight (kg) | 35 |
| Width (mm) | 176 |
| Height (mm) | 251,3 |
Obtain a Quote for Servo Motors HG-JR7034B at economical prices. Specifications Overview for HG-JR7034B reveals MELSERVO-J4 HG-JR at the best prices. This high-performance unit has a rated capacity of 7 kW, delivering 22,3 Nm of rated torque and a maximum torque of 66,8 Nm, ensuring precise motion control. With a rated speed of 3000 rpm and a maximum speed of 5000 rpm, it supports high-speed applications. The low inertia 52,9 allows for smooth and responsive operation. Designed with a AC current type, it features an advanced 22-BIT-bit encoder with 4194304 pulses per revolution, ensuring exceptional accuracy. The IP67 protection class safeguards against dust and water, making it reliable in industrial environments. Its compact build, with a depth of 392 mm, the width of 176 mm, and height of 251,3 mm, ensures easy installation. Take the First Step with a Quote for your requirement of Servo Motors. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
