Mitsubishi FX5-C32ET/DSS - Programmable Logic Controller
The Mitsubishi FX5-C32ET/DSS PLC is an advanced I/O combined module from the MELSEC iQ-F series, designed to streamline digital input-output control in compact industrial automation systems.
| Brand | Mitsubishi |
| Product Type | PLC(Programmable Logic Controller) |
| Product | FX5-C32ET/DSS |
Technical Specifications of Mitsubishi Programmable Logic Controller FX5-C32ET/DSS
| Specification | Value |
|---|---|
| Series | MELSEC IQ-F SERIES |
| Type | I/O COMBINED MODULE |
| Occupied I/O Points on PLC | 32 |
| Integrated Digital Inputs | 16 |
| Depth (mm) | 87 |
| Weight (kg) | 119 |
| Width (mm) | 20,1 |
| Height (mm) | 90 |
| Power Supply (V) | 24 |
| Current Type | DC |
| Integrated Digital Outputs | 16 |
| Output Type | TRANSISTOR |
| Output Logic | SOURCE |
The Mitsubishi FX5-C32ET/DSS is a space-saving yet powerful PLC base unit engineered for high-speed digital control. It features 32 occupied I/O points, divided into 16 digital inputs and 16 digital transistor outputs, offering seamless integration into discrete automation tasks. Built with source output logic, it ensures stable signal switching, ideal for interfacing with sensors, relays, and actuators commonly found on factory floors. Its 24V DC power supply and low internal current consumption enable efficient and reliable operation, even under extended duty cycles.
Physically compact, the unit measures just 87 mm in depth, 20.1 mm in width, and 90 mm in height, making it well-suited for dense control panels or modular system designs. Weighing approximately 119 grams (not kg β likely a typo in source data), it supports DIN rail mounting for easy installation. The MELSEC iQ-F platform also supports intelligent diagnostics, built-in security features, and high-speed processing to meet the growing demands of smart manufacturing. Trusted by automation professionals across automotive, textile, packaging, and machine-building industries, the FX5-C32ET/DSS strikes the perfect balance between performance and cost-efficiency.
For engineers seeking dependable digital I/O control with fast switching speed and robust build quality, the Mitsubishi FX5-C32ET/DSS PLC remains a top choice. Its combination of transistor output precision, compact design, and seamless compatibility with Mitsubishiβs ecosystem makes it an excellent solution for modern automation challenges.
The Mitsubishi FX5-C32ET/DSS PLC is commonly used in industrial applications that require compact digital I/O control with high-speed signal processing. It's especially effective in machine control panels where both sensor inputs and actuator outputs are handled from a single compact unit.
In packaging machines, itβs used to manage sensors for box detection and to trigger outputs for pneumatic actuators that sort, cut, or seal. In textile and bottling lines, the transistor outputs offer rapid switching for solenoids and control signals, reducing cycle times. Its reliable source-type transistor output logic ensures signal clarity and protection when paired with industrial PLC-compatible sensors and devices.
Engineering students and junior technicians will appreciate the simplicity and clarity of its wiring, while senior maintenance engineers trust the FX5-C32ET/DSS for its long-term performance and diagnostic tools. For anyone designing or maintaining fast-paced automated systems, the Mitsubishi FX5-C32ET/DSS PLC is a dependable and high-value component.
