Mitsubishi FR-F840-00470-E2-60 Variable Frequency Drive
Technical Specifications of Mitsubishi Variable Frequency Drive FR-F840-00470-E2-60:
| Brand | Mitsubishi |
| Product Type | Variable Frequency Drive |
| Product | FR-F840-00470-E2-60 |
Mitsubishi Variable Frequency Drive FR-F840-00470-E2-60 Technical Specifications:
| Specification | Value |
|---|---|
| Series | FR-F800 SERIES |
| Type | FR-F800-E INVERTER |
| Minimum Rated Voltage (V) | 380 |
| Min. Permissible Voltage (V) | 323 |
| Maximum Rated Voltage (V) | 500 |
| Max. Permissible Voltage (V) | 550 |
| Current Type | AC |
| Phases | 3 |
| Frequency Range (Hz) | 0,2β590 |
| Control Method | V/F CONTROL, SOFT-PWM/HIGH FREQUENCY PWM, PM SENSORLESS VECTOR CONTROL, MAGNETIC FLUX VECTOR CONTROL |
| Motor Type | INDUCTION MOTOR, PM MOTOR |
| Integrated EMC Filter | YES |
| Safe Torque Off (STO) | YES |
| Regenerative (4Q) | NO |
| Integrated DC Choke | NO |
| Display | FR-DU08 |
| Display Type | 5 DIGITS LED (12 SEGMENT) |
| PLC Function | YES |
| Program Memory | 6K |
| Program Memory Unit | STEPS |
| Integrated Digital Inputs | 12 |
| Digital Outputs (Transistor) | 5 |
| Digital Outputs (Relay) | 2 |
| Integrated Analogue Inputs | 3 |
| Integrated Analogue Outputs | 2 |
| IO Type of Terminal Block | SPRING CLAMP |
| Expandable | YES |
| USB | 1+1 MINI |
| Ethernet Port | 1 |
| Built-In Network | CC-LINK IE FIELD NETWORK BASIC, MELSOFT/FA, iQSS, MODBUS/TCP, SLMP, BACNET/IP |
| Leakage Current (mA) | 35(DELTA) / 2(STAR) |
| Protection Class | IP20 |
| Depth (mm) | 190 |
| Weight (kg) | 15 |
| Width (mm) | 250 |
| Height (mm) | 400 |
| Standby Power Consumption (W) | 20 |
| Rated Output Current LD (A) | 43 |
| Rated Motor Capacity LD (kW) | 22 |
| Power Loss LD (W) | 520 |
| Rated Output Current SLD (A) | 47 |
| Rated Motor Capacity SLD (kW) | 22 |
| Power Loss SLD (W) | 565 |
| Shipping Approvals | DNV,ABS |
The Mitsubishi FR-F840-00470-E2-60 Variable Frequency Drive is designed for stable motor control in industrial automation systems. This Mitsubishi model supports 22 kW output power, provides 47 A rated current and operates on a 380β500 V AC three-phase supply. As part of the FR-F800 SERIES, it offers vector and PWM-based control modes suitable for induction and PM motors in demanding environments.
The Mitsubishi FR-F840-00470-E2-60 Variable Frequency Drive is commonly used in conveyors, packaging equipment, material movement systems and assembly-line automation. Its LED display, extensive digital I/O, Ethernet connectivity and relay outputs ensure consistent motor regulation. The IP20 enclosure and spring-clamp terminals make integration into industrial control panels efficient and reliable.
The Mitsubishi FR-F840-00470-E2-60 Variable Frequency Drive provides dependable performance with vector control, IP20 protection and a durable three-phase operating range. As a member of the Mitsubishi FR-F800 SERIES, it is trusted for smooth operation, long-term reliability and compatibility with industrial motors. Engineers choose this model for stable torque control and seamless integration into automation systems.
