Mitsubishi FR-E840-0440-4-60 Variable Frequency Drive
Technical Specifications of Mitsubishi Variable Frequency Drive FR-E840-0440-4-60:
| Brand | Mitsubishi |
| Product Type | Variable Frequency Drive |
| Product | FR-E840-0440-4-60 |
Mitsubishi Variable Frequency Drive FR-E840-0440-4-60 Technical Specifications:
| Specification | Value |
|---|---|
| Series | FR-E800 SERIES |
| Type | FR-E800 RS485 INVERTER |
| Minimum Rated Voltage (V) | 380 |
| Min. Permissible Voltage (V) | 323 |
| Maximum Rated Voltage (V) | 480 |
| Max. Permissible Voltage (V) | 528 |
| Current Type | AC |
| Phases | 3 |
| Rated Output Current ND (A) | 44 |
| Rated Motor Capacity ND (kW) | 22 |
| Frequency Range (Hz) | 0,2β590 |
| Control Method | V/F CONTROL, REAL SENSORLESS VECTOR CONTROL, PM SENSORLESS VECTOR CONTROL, MAGNETIC FLUX VECTOR CONTROL |
| Motor Type | INDUCTION MOTOR, PM MOTOR |
| Brake Chopper ED (%) | 100 |
| Integrated EMC Filter | NO |
| Safe Torque Off (STO) | YES |
| Regenerative (4Q) | NO |
| Integrated DC Choke | NO |
| Display | BUILT-IN |
| Display Type | 4 DIGITS LED |
| PLC Function | YES |
| Program Memory | 2K |
| Program Memory Unit | STEPS |
| Integrated Digital Inputs | 7 |
| Digital Outputs (Transistor) | 2 |
| Digital Outputs (Relay) | 1 |
| Integrated Analogue Inputs | 2 |
| Integrated Analogue Outputs | 1 |
| IO Type of Terminal Block | SPRING CLAMP |
| Expandable | YES |
| RS-485 | 1 |
| USB | 1 (MINI B) |
| Ethernet Port | NO |
| Built-In Network | MODBUS-RTU |
| Leakage Current (mA) | 1,2 |
| Power Loss ND (W) | 401 |
| Protection Class | IP20 |
| Depth (mm) | 190 |
| Weight (kg) | 11 |
| Width (mm) | 220 |
| Height (mm) | 350 |
| Rated Output Current LD (A) | 60 |
| Rated Motor Capacity LD (kW) | 30 |
| Power Loss LD (W) | 589 |
The Mitsubishi FR-E840-0440-4-60 Variable Frequency Drive is a robust industrial controller designed for stable motor operation across automation systems. This Mitsubishi model supports 22 kW motor capacity, delivers 44 A rated output current and operates on a 380β480 V AC three-phase supply. As part of the FR-E800 SERIES, it offers multiple vector control modes for induction and PM motors and is widely used in industrial automation environments.
Industries use the Mitsubishi FR-E840-0440-4-60 Variable Frequency Drive for conveyors, packaging machinery, material handling and assembly lines. Its stable control, Modbus-RTU communication, 7 digital inputs and LED display enable precise motor regulation. The driveβs IP20 protection and flexible I/O design support reliable use in control panels and machine-level automation applications.
The Mitsubishi FR-E840-0440-4-60 Variable Frequency Drive combines vector control, IP20 protection and dependable performance across varied industrial loads. Being part of the Mitsubishi FR-E800 SERIES reinforces its suitability for demanding automation tasks. Engineers choose this model for consistent motor control, long-term reliability and seamless integration within industrial systems.
