Mitsubishi Variable Frequency Drive FR-E840-0300EPC-60 Technical Specifications:
Specification
Value
Series
FR-E800 SERIES
Type
FR-E800-ETH INVERTER
Minimum Rated Voltage (V)
380
Min. Permissible Voltage (V)
323
Maximum Rated Voltage (V)
480
Max. Permissible Voltage (V)
528
Current Type
AC
Phases
3
Rated Output Current ND (A)
30
Rated Motor Capacity ND (kW)
15
Frequency Range (Hz)
0,2β590
Control Method
V/F CONTROL, MAGNETIC FLUX VECTOR CONTROL, PM SENSORLESS VECTOR CONTROL, REAL SENSORLESS VECTOR CONTROL
Motor Type
INDUCTION MOTOR, PM MOTOR
Brake Chopper ED (%)
100
Integrated EMC Filter
NO
Safe Torque Off (STO)
YES
Regenerative (4Q)
NO
Integrated DC Choke
NO
Display
BUILT-IN
Display Type
4 DIGITS LED
PLC Function
YES
Program Memory
2K
Program Memory Unit
STEPS
Integrated Digital Inputs
2
Digital Outputs (Relay)
1
Integrated Analogue Inputs
2
IO Type of Terminal Block
SPRING CLAMP
Expandable
YES
RS-485
NO
USB
1 (MINI B)
Ethernet Port
2
Built-In Network
ETHERCAT
Leakage Current (mA)
1,2
Power Loss ND (W)
321
Protection Class
IP20
Depth (mm)
190
Weight (kg)
4,9
Width (mm)
220
Height (mm)
260
Rated Output Current LD (A)
41
Rated Motor Capacity LD (kW)
18,5
Power Loss LD (W)
486
Please speak to our Technical Engineer for Variable Frequency Drive FR-E840-0300EPC-60 at attractive prices. Technical Specs Summary of FR-E840-0300EPC-60 includes FR-E800-ETH INVERTER from the FR-E800 SERIES at competitive prices. This AC inverter operates on 3-phase power with a minimum rated voltage of 380V, a minimum permissible voltage of 323V, a maximum rated voltage of 480V, and a maximum permissible voltage of 528V. It is designed with an IP20 protection class, ensuring safe operation in controlled environments. The inverter has a compact build, with a depth of 190 mm, a width of 220 mm, and a height of 260 mm, making it suitable for space-constrained installations. It weighs 4,9 kg, ensuring easy handling and installation. Match Your Needs with a Quote for your requirement of Variable Frequency Drive. We lead with pricing that's more favorable and support that's more attentive than other Suppliers & Traders.
