Mitsubishi FR-E840-0300-4-60 Variable Frequency Drive
Technical Specifications of Mitsubishi Variable Frequency Drive FR-E840-0300-4-60:
| Brand | Mitsubishi |
| Product Type | Variable Frequency Drive |
| Product | FR-E840-0300-4-60 |
Mitsubishi Variable Frequency Drive FR-E840-0300-4-60 Technical Specifications:
| Specification | Value |
|---|---|
| Series | FR-E800 SERIES |
| Type | FR-E800 RS485 INVERTER |
| Minimum Rated Voltage (V) | 380 |
| Min. Permissible Voltage (V) | 323 |
| Maximum Rated Voltage (V) | 480 |
| Max. Permissible Voltage (V) | 528 |
| Current Type | AC |
| Phases | 3 |
| Rated Output Current ND (A) | 30 |
| Rated Motor Capacity ND (kW) | 15 |
| Frequency Range (Hz) | 0,2β590 |
| Control Method | V/F CONTROL, REAL SENSORLESS VECTOR CONTROL, PM SENSORLESS VECTOR CONTROL, MAGNETIC FLUX VECTOR CONTROL |
| Motor Type | INDUCTION MOTOR, PM MOTOR |
| Brake Chopper ED (%) | 100 |
| Integrated EMC Filter | NO |
| Safe Torque Off (STO) | YES |
| Regenerative (4Q) | NO |
| Integrated DC Choke | NO |
| Display | BUILT-IN |
| Display Type | 4 DIGITS LED |
| PLC Function | YES |
| Program Memory | 2K |
| Program Memory Unit | STEPS |
| Integrated Digital Inputs | 7 |
| Digital Outputs (Transistor) | 2 |
| Digital Outputs (Relay) | 1 |
| Integrated Analogue Inputs | 2 |
| Integrated Analogue Outputs | 1 |
| IO Type of Terminal Block | SPRING CLAMP |
| Expandable | YES |
| RS-485 | 1 |
| USB | 1 (MINI B) |
| Ethernet Port | NO |
| Built-In Network | MODBUS-RTU |
| Leakage Current (mA) | 1,2 |
| Power Loss ND (W) | 321 |
| Protection Class | IP20 |
| Depth (mm) | 190 |
| Weight (kg) | 4,9 |
| Width (mm) | 220 |
| Height (mm) | 260 |
| Rated Output Current LD (A) | 41 |
| Rated Motor Capacity LD (kW) | 18,5 |
| Power Loss LD (W) | 486 |
The Mitsubishi FR-E840-0300-4-60 Variable Frequency Drive is part of the FR-E800 SERIES designed for efficient motor control in industrial automation. It provides 15kW motor capacity, 30A rated output current, and operates across a frequency range of 0.2β590Hz. This Mitsubishi Variable Frequency Drive uses V/F and PM Sensorless Vector Control to ensure smooth performance and energy efficiency across various industrial applications.
The Mitsubishi FR-E840-0300-4-60 is ideal for use in conveyors, packaging systems, pumps, and factory automation lines. It enables seamless integration through RS-485 MODBUS-RTU connectivity and maintains steady control with Magnetic Flux Vector Control. The built-in LED display allows easy configuration, and the Safe Torque Off (STO) feature ensures enhanced operator safety during operation.
The Mitsubishi FR-E840-0300-4-60 Variable Frequency Drive offers 15kW output power with reliable torque control and compact design. As part of Mitsubishiβs trusted FR-E800 SERIES, it provides robust performance, long-term dependability, and precise control for diverse industrial environments β making it a preferred choice for automation systems in India.
