Mitsubishi FR-E840-0230-4-60 Variable Frequency Drive
Technical Specifications of Mitsubishi Variable Frequency Drive FR-E840-0230-4-60:
| Brand | Mitsubishi |
| Product Type | Variable Frequency Drive |
| Product | FR-E840-0230-4-60 |
Mitsubishi Variable Frequency Drive FR-E840-0230-4-60 Technical Specifications:
| Specification | Value |
|---|---|
| Series | FR-E800 SERIES |
| Type | FR-E800 RS485 INVERTER |
| Minimum Rated Voltage (V) | 380 |
| Min. Permissible Voltage (V) | 323 |
| Maximum Rated Voltage (V) | 480 |
| Max. Permissible Voltage (V) | 528 |
| Current Type | AC |
| Phases | 3 |
| Rated Output Current ND (A) | 23 |
| Rated Motor Capacity ND (kW) | 11 |
| Frequency Range (Hz) | 0,2β590 |
| Control Method | V/F CONTROL, REAL SENSORLESS VECTOR CONTROL, PM SENSORLESS VECTOR CONTROL, MAGNETIC FLUX VECTOR CONTROL |
| Motor Type | INDUCTION MOTOR, PM MOTOR |
| Brake Chopper ED (%) | 100 |
| Integrated EMC Filter | NO |
| Safe Torque Off (STO) | YES |
| Regenerative (4Q) | NO |
| Integrated DC Choke | NO |
| Display | BUILT-IN |
| Display Type | 4 DIGITS LED |
| PLC Function | YES |
| Program Memory | 2K |
| Program Memory Unit | STEPS |
| Integrated Digital Inputs | 7 |
| Digital Outputs (Transistor) | 2 |
| Digital Outputs (Relay) | 1 |
| Integrated Analogue Inputs | 2 |
| Integrated Analogue Outputs | 1 |
| IO Type of Terminal Block | SPRING CLAMP |
| Expandable | YES |
| RS-485 | 1 |
| USB | 1 (MINI B) |
| Ethernet Port | NO |
| Built-In Network | MODBUS-RTU |
| Leakage Current (mA) | 1,2 |
| Power Loss ND (W) | 239 |
| Protection Class | IP20 |
| Depth (mm) | 190 |
| Weight (kg) | 4,8 |
| Width (mm) | 220 |
| Height (mm) | 260 |
| Rated Output Current LD (A) | 35 |
| Rated Motor Capacity LD (kW) | 15 |
| Power Loss LD (W) | 410 |
The Mitsubishi FR-E840-0230-4-60 Variable Frequency Drive is a compact and efficient model in the FR-E800 SERIES, designed for high-performance motor control in industrial environments. It offers a 380β480V AC 3-phase input, 11kW output capacity, and 23A rated current. This Mitsubishi Variable Frequency Drive supports V/F and Sensorless Vector Control, ensuring precise torque and speed management for both induction and PM motors.
The Mitsubishi FR-E840-0230-4-60 is used across conveyors, pumps, packaging systems, and assembly automation where stability and energy efficiency are critical. With its Safe Torque Off (STO) safety function and integrated PLC control, it enhances operational reliability. Its spring clamp terminal design and built-in Modbus-RTU network make it simple to install and integrate into control systems.
The Mitsubishi FR-E840-0230-4-60 Variable Frequency Drive combines 11kW rated output and IP20 protection with Mitsubishiβs proven engineering for reliable industrial use. Belonging to the FR-E800 SERIES, it offers efficient motor control and connectivity for modern automation setups. Trusted by engineers in India, this model ensures dependable performance, long-term durability, and smooth operation across a wide range of applications.
