Mitsubishi FR-E820S-0080EPA-60 Variable Frequency Drive
Technical Specifications of Mitsubishi Variable Frequency Drive FR-E820S-0080EPA-60:
| Brand | Mitsubishi |
| Product Type | Variable Frequency Drive |
| Product | FR-E820S-0080EPA-60 |
Mitsubishi Variable Frequency Drive FR-E820S-0080EPA-60 Technical Specifications:
| Specification | Value |
|---|---|
| Series | FR-E800 SERIES |
| Type | FR-E800-ETH INVERTER |
| Minimum Rated Voltage (V) | 200 |
| Min. Permissible Voltage (V) | 170 |
| Maximum Rated Voltage (V) | 240 |
| Max. Permissible Voltage (V) | 264 |
| Current Type | AC |
| Phases | 1 |
| Rated Output Current ND (A) | 8 |
| Rated Motor Capacity ND (kW) | 1,5 |
| Frequency Range (Hz) | 0,2–590 |
| Control Method | V/F CONTROL, REAL SENSORLESS VECTOR CONTROL, PM SENSORLESS VECTOR CONTROL, MAGNETIC FLUX VECTOR CONTROL |
| Motor Type | INDUCTION MOTOR, PM MOTOR |
| Brake Chopper ED (%) | 100 |
| Integrated EMC Filter | NO |
| Safe Torque Off (STO) | YES |
| Regenerative (4Q) | NO |
| Integrated DC Choke | NO |
| Display | BUILT-IN |
| Display Type | 4 DIGITS LED |
| PLC Function | YES |
| Program Memory | 2K |
| Program Memory Unit | STEPS |
| Integrated Digital Inputs | 2 |
| Digital Outputs (Relay) | 1 |
| Integrated Analogue Inputs | 2 |
| IO Type of Terminal Block | SPRING CLAMP |
| Expandable | YES |
| RS-485 | NO |
| USB | 1 (MINI B) |
| Ethernet Port | 2 |
| Built-In Network | BACNET/IP, MODBUS/TCP, ETHERNET/IP, CC-LINK IE TSN, CC-LINK IE FIELD BASIC |
| Leakage Current (mA) | 1,2 |
| Power Loss ND (W) | 81 |
| Protection Class | IP20 |
| Depth (mm) | 161 |
| Weight (kg) | 1,4 |
| Width (mm) | 108 |
| Height (mm) | 128 |
IndMALL Automation Dealing offers Variable Frequency Drive FR-E820S-0080EPA-60 at unbeatable prices. The Main Technical Parameters of FR-E820S-0080EPA-60 are FR-E800-ETH INVERTER from the FR-E800 SERIES at competitive prices. This AC inverter operates on 1-phase power with a minimum rated voltage of 200V, a minimum permissible voltage of 170V, a maximum rated voltage of 240V, and a maximum permissible voltage of 264V. It is designed with an IP20 protection class, ensuring safe operation in controlled environments. The inverter has a compact build, with a depth of 161 mm, a width of 108 mm, and a height of 128 mm, making it suitable for space-constrained installations. It weighs 1,4 kg, ensuring easy handling and installation. Take the First Step with a Quote for your requirement of Variable Frequency Drive. Choose us for unparalleled pricing and support over other Dealers & Distributors.
